Decurler and Paper Transportation
2
2
3
3
1
2
DECURLER CAM HOME SENSOR PL17.8
12.11A
12.6
12.11A
12.3 12.3 12.4
3
1
2
COMPILER ENTRANCE SENSOR PL17.12
4
1
3 4
2
4
12.5 DECURLER AND PAPER TRANSPORTATION
FINISHER PWB PL17.13
+5VDC
DC CON
DC CON
J849
GRY
VIO
J846
RT5
INTLK ON
+5VDC
3 1 2 1
DC330 [12-070]
[12-071]
DECURLER CAM
CLUTCH ON (L) +24VDC
BLU
ORN
INTLK ON
+24VDC
J880
DOUBLE
PLUG
P880
DECURLER CAM CLUTCH PL17.7
2 1
2 1
J884
J884
DC330 [12-217]
DECURLER CAM HOME
SENSOR
BLOCKED (L) +5VDC
J849
YEL
2
FINISHER PWB PL17.13
+5VDC
DECURLER CAM
HOME SENSOR
SENSED SIGNAL
DECURLER ROLL
DRIVE
EXIT ROLL DRIVE
PAPER TO
DECURLER
FINISHER PWB PL17.13
+5VDC
DC COM
B9 B7
J850
J870B
GRY
VIO
GRY
VIO
1 3
6 4
DOUBLE
PLUG
J870A
J867
J867
YEL YEL
J870A J870B
DOUBLE
PLUG
52
DC330 [12-101]
COMPILER ENTRANCE
SENSOR
PAPER SENSED (H) +5VDC
J850
B8
+5VDC
FINISHER PWB PL17.13
COMPILER
ENTRANCE
SENSOR
SENSED SIGNAL
DECURLER
PAPER
7750-331
When M/C provides the info that one of paper LE and TE has a 10mm-or-more upper curl, Decurler operates. Decurler Cam Clutch is kept on until the Decurler Cam Home Sensor is in the “H” level (receives light= in desurl position). If the sensor is in “L” from the beginning, Decurler doesn’t operate. Turning on [12-071] leads to the operation below: Finisher Drive Motor on + Decurler Cam Clutch on Stops with Decurler Cam Home Sensor in “L”.
