Xerox 7750DXF - Phaser Color Laser Printer User Manual

11-41
Stacker Tray Control (cont’d)
UPPER LIMIT SENSOR PL17.11
3 1
2
STACK A SENSOR PL17.11
3 1
2
STACK B SENSOR PL17.11
3 1
2
FINISHER PWB PL17.13
DC COM DC COM DC COM
+5VDC +5VDC +5VDC
A10 A12
A7 A9 A4 A6
J850
J862
VIO VIO VIO
GRY GRY GRY
J862
J863
J863
J864
J864
2
1
3 3 3
2
1
2
3
DC330 [12-204]
STACK A SENSOR
BLOCKED (H) +5VDC
DC330 [12-202]
UPPER LIMIT SENSOR
LIMIT SENSED (H) +5VDC
DC330 [12-205]
STACK B SENSOR
BLOCKED (H) +5VDC
YEL YEL YEL
J850
FINISHER PWB PL17.13
+5VDC +5VDC +5VDC
A11
A8 A5
UPPER LIMIT
SENSOR
SENSED SIGNAL
STACK A SENSOR
SENSED SIGNAL
STACK B SENSOR
SENSED SIGNAL
12.11B 12.11B 12.11B
12.10B STACKER TRAY CONTROL (2 OF 2)
UPPER LIMIT SENSOR
STACK A SENSOR
STACK B SENSOR
A5 LEF B5 LEF A4 LEF 8.5X11 LEF 16K LEF Post Card SEF B6 SEF A6 SEF A5SEF B5 SEF A4 SEF B4 SEF A3 SEF 5.5X8.5 SEF 8X10 SEF 8.5X11 SEF 8.5X13 SEF 8.5X14 SEF 8K SEF 11X17 SEF 12X18 SEF 12.6X18 SEF
X
1000 1000 1000 1000
X X X X X
1000
500 500
X
1000 1000
500 500 500 500
X X
X
50 50 50 50
X X X X X
50 50 50
X
50 50 50 50 50 50
X X
paper size paper qty set qty
Stacker Tray can hold the following:
NOTES:
X: unavailable
Virtual Line
OFF
ON ON
OFF
OFF OFF
ON ON
0-300 sheets
300-500 sheets
500-1000 sheets
Over 1000 sheets
STACK
A SENSOR
STACK
B SENSOR
Capacity
The combination of Stack A Sensor and Stack B Sensor states
determines the qty of paper sheets to be held.
ON: blocks light
OFF: receives light
7750-337
