Top Cover and Eject Roll PL 17.6
No. Part Number Qty Description
1
116-1262-00 1 Top Open Cover Assembly
2
Arm
3
Bearing
4
Bracket
5
Spring
6
Support
7
Bracket
8
Shaft
9
116-1302-00 1 Eject Pinch Roll
10
116-1823-00 1 Eject Chute
11
116-1272-00 1 Stack Height Sensor Assembly
12
1 Actuator
13
Bracket
14
116-1253-00 1 Stack Height Sensor
15
Shaft
16
Link
17
116-1264-00 1 Actuator
18
116-1258-00 Clutch
19
Collar
20
116-1848-00 1 Gear (28Z) part of a kit
21
Eject Roll
22
116-1848-00 1 Gear (20T) part of a kit
23
Bearing
24
Eject Shaft
25
116-1302-00 1 Eject Roll Assembly
26
Link
27
Static Eliminator
28
Collar
