Xerox 7750DXF - Phaser Color Laser Printer - Page 469

11-53
Paper Transport: 1 of 2 PL 17.7
No. Part Number Qty Description
1
116-1248-00 1 Actuator Cam
2
116-1249-00 1 Clutch Assembly, Decurler Cam
3
Cam
4
Shaft
5
Bearing
6
116-1250-00 1 Arm
7
116-1302-00 1 Decurler Roll
8
116-1847-00 1 Gear (40Z / 20T) - part of a kit
9
116-1847-00 1 Gear (40Z) - part of a kit
10
116-1847-00 1 Gear (18Z / 21T) - part of a kit
11
Shaft
12
Bearing
13
116-1847-00 1 Gear (23Z / 52Z) - part of a kit
14
116-1265-00 1 Belt
15
116-1242-00 1 Belt
16
116-1241-00 1 Finisher Drive Motor
17
Bracket
