11-55
Paper Transport: 2 of 2 PL 17.8
No. Part Number Qty Description
1
116-1266-00 1 Cam Bracket Assembly
2
116-1847-00 1 Pully - part of a kit
3
116-1847-00 1 Gear (15Z) - part of a kit
4
116-1271-00 1 Belt
5
116-1847-00 1 Gear (30Z) - part of a kit
6
Collar
7
116-1847-00 1 Gear Pully - part of a kit
8
Eject Motor
9
116-1847-00 1 Cam Gear - part of a kit
10
116-1847-00 1 Gear (42Z / 27Z) - part of a kit
11
Set Clamp Solenoid
12
Bracket
13
Wire Harness
14
116-1234-00 1 Home Sensor
15
Plate
16
17
18
Bracket
19
Stop
20
Spring
