11-57
Staple Unit Assembly PL 17.9
No. Part Number Qty Description
1
116-1255-00 1 Carriage Assembly (Item 2-6)
2
Bracket Assembly
3
116-1256-00 1 Staple Move Motor
4
Gear
5
Staple Sensor
6
Roll
7
116-1259-00 1 Staple Front Corner Sensor
8
Plate
9
116-1254-00 1 Rail (REP 17.9.1)
10
116-1257-00 1 Stapler Assembly (Item 11.12) (REP 17.9.2)
11
Stapler
12
Cartridge
13
Bracket
14
Stapler Harness
