Xerox 7750DXF - Phaser Color Laser Printer User Manual

11-61
Stacker Elevator Assembly PL 17.11
No. Part Number Qty Description
1
116-1287-00 1 Stacker Motor Assembly
2
116-1276-00 1 Front Elevator Bracket
3
Clamp
4
Bearing
5
116-1274-00 1 Gear (Rear)
6
Actuator
7
116-1275-00 1 Gear (Front)
8
Stacker Tray Bracket Assembly
9
116-1273-00 1 Rack
10
Tray Guide
11
116-1270-00 1 Paper Stack Assembly (Item 12-16)
12
116-1253-00 1 Sensor
13
Actuator
14
Bracket
15
Spring
16
Cover
17
Bracket
18
116-1253-00 Upper Limit /Stack A /Stack B Sensor
19
Bracket
20
Pin
21
Bearing
22
Shaft
23
Rivot
