Xerox 7750DXF - Phaser Color Laser Printer User Manual

11-63
Exit Assembly PL 17.12
No. Part Number Qty Description
1
Gear (48Z)
2
Bearing
3
116-1243-00 1 Exit Shaft
4
Collar
5
Gear (32Z / 18T)
6
Bearing
7
116-1304-00 1 Paddle Gear Shaft (REP 17.12.1)
8
Paddle Bearing
9
Lower Exit Chute
10
116-1302-00 1 Pinch Roll (Exit 1)
11
Pinch Roll (Exit 2)
12
Pinch Roll (Exit 3)
13
Upper Exit Chute
14
116-1240-00 1 Compiler Entrance Sensor
15
Plate Spring
16
Bracket
17
Static Eliminator
