11-65
Electrical Components PL 17.13
No. Part Number Qty Description
1
Board Cover
2
116-1235-00 1 Finisher Board
3
116-1314-00 1 ROM
4
PWB Bracket
5
116-1824-00 DC Harness
6
116-1825-00 Cable
7
116-1233-00 1 Top Cover/Front Door Interlock Switch
8
116-1253-00 1 Docking Interlock Switch
9
Spring Plate
10
Bracket
11
Plate
