February, 2008
6-32
WorkCentre 5225, 5230
IIT NVM List
Launch Version
General Procedures
Chain 710-xxx DADF
Table 1 DADF
Chain-Link Content Default Range Meaning
710-501 Fax Document Size Detection Method for DADF 0 0~1 Switches detection methods when Fax Document Size Detection is specified in DADF mode. 0: A/B
series, 1: Inch series
710-551 JAM Bypass 0 0~1 0: Do not bypass, 1: Bypass. Also applies to CVT mode.
710-556 8.5”x11” LEF Threshold 2093 1993~2193 Threshold value for distinguishing 8.5”x11” LEF from 8”x10” LEF
710-557 B5 SEF/8”x10” SEF Switching 0 0~1 0: B5 SEF (FX/XE/AP), 1: 8”x10” SEF (XC)
710-558 11”x15” SEF/8-k Switching (for AP market) 0 0~1 0: 11”x15” SEF, 1: 8 k
710-559 FS MAX Value 2970 1297~3070 DADF document size detection table for registration by customers
710-560 FS MIN Value 2970 1297~3070 DADF document size detection table for registration by customers
710-561 SS MAX Value 2100 1297~4418 DADF document size detection table for registration by customers
710-562 SS MIN Value 2100 1297~4418 DADF document size detection table for registration by customers
710-563 Document Size 8 3~20 DADF document size detection table for registration by customers
710-564 Document Process Direction 0 0~1 DADF document size detection table for registration by customers
710-565 DADF Document Size Detection Table 0 0~1 DADF document size detection table for registration by customers
710-566 Lead Registration Correction for Side 2 of S-sized
documents
250 217~283 Lead registration correction value for Side 2 of S-sized documents. (Unit = step.) S-sized paper with
a length between 131.7mm and 158.0mm in the slow scan direction.
710-567 Lead Registration Correction for Side 2 of M-sized
documents
250 217~283 Lead registration correction value for Side 2 of M-sized documents. (Unit = step.) M-sized paper with
a length between 158.1mm and 245.9mm in the slow scan direction.
710-568 Lead Registration Correction for Side 2 of L-sized
documents
250 217~283 Lead registration correction value for Side 2 of L-sized documents. (Unit = step.) L-sized paper with
a length between 246.0mm and 460.0mm in the slow scan direction.
710-600 Size Mismatch Jam Detection Setting (Applicable
only in Simplex mode)
1 1~2 1: Size Mismatch Jam Detection On 2: Size Mismatch Jam Detection Off
710-601 Alternate Size Set 1 1 1~2 PF1: Switches between 8.5x13 SEF and 8.46x12.4 SEF No-Mix/Size-Mix: Inch 13
1: 8.5x13 SEF, 2: 8.46x12.4 SEF
710-602 Alternate Size Set 2 1 1~2 PF1: Switches between 8.5x14 SEF and 8.46x12.4 SEF No-Mix/Size-Mix: Inch 14
1: 8.5x14 SEF, 2: 8.46x12.4 SEF
710-603 Alternate Size Set3 0 0~2 PF1: Switches between 11x15S and 11x17S. No-Mix: mm, No-Mix/Size-Mix: Inch13/Inch14,0:
Default,1: 11x17S,2: 11x15S PF2: Switches between 11x15S and 11x17S. No-Mix: mm/Inch13/
Inch14, Size-Mix: Inch13/Inch14,0: Default,1: 11x17S,2: 11x15S
710-604 Alternate Size Set4 0 0~2 PF1: Switches between 8.46x12.4S, 8.5x13S and 8.5x14S. No-Mix/Size-Mix: mm,0: Default,1:
8.5x13S,2: 8.5x14S PF2: Switches between 8.5x13S and 8.5x14S. No-Mix/Size-Mix: mm Initial
value: 2,0: Default,1: 8.5x13S,2: 8.5x14S
710-605 Alternate Size Set5 0 0~2 PF1: Switches between BS5 and 16KS. No-Mix: mm,0: Default,1: B5S,2: 16KS PF2: Switches
between B5S and 16KS. No-Mix/Size-Mix: mm 0: Default,1: B5S, 2: 16KS
710-606 Alternate Size Set6 0 0~3 PF1: Switches between 8x10S, 8x10.5S and 8.5x11S. Size-Mix: Inch13/Inch14,0: Default,1:
8.5x11S,2: 8x10S,3: 8x10.5S PF2: Switches between 8x10S, 8x10.5S and 8.5x11S. Size-Mix:
Inch13/Inch14,0: Default,1: 8.5x11S,2: 8x10S,3: 8x10.5S
710-607 Alternate Size Set7 0 0~3 PF1: Switches between 8x10L, 8x10.5L and 8.5x11L. Size-Mix: Inch13/Inch14,0: Default,1:
8.5x11L,2: 8x10L,3: 8x10.5L PF2: Switches between 8x10L, 8x10.5L and 8.5x11L. Size-Mix: Inch13/
Inch14,0: Default,1: 8.5x11L,2: 8x10L,3: 8x10.5L
710-608 Alternate Size Set8 0 0~3 PF2: Switches between B4S, 8KS, 11x15S and 11x17S. Size-Mix: mm,0: Default,1: B4S,2: 8KS 3:
11x15S 4: 11x17S PF2: Switches between B4S, 8KS and 11x17S. Size-Mix: mm,0: Default,1:
B4S,2: 8KS 3: 11x17S PF2 setting range is 0~3.
