February, 2008
6-33
WorkCentre 5225, 5230
IIT NVM List
General Procedures
Launch Version
Chain 715-xxx IISS
710-609 Alternate Size Set9 0 0~2 PF1: Switches between 8x10S and 8x10.5S. No-Mix: Inch13/Inch14,0: Default,1: 8x10S,2: 8x10.5S
PF2: Switches between 8x10S and 8x10.5S. No-Mix: Inch13/Inch14,0: Default,1: 8x10S,2: 8x10.5S
710-610 Alternate Size Set10 0 0~2 PF1: Switches between B5L and 16KL. Size-Mix: mm,0: Default,1: B5L,2: 16KL PF2: Switches
between B5L, 16KL and 8.5x11L. Size-Mix: mm,0: Default 1: B5L,2: 16KL 3: 8.5x11L PF2 setting
range is 0~3.
710-611 Alternate Size Set11 0 0~3 PF1: Switches between B5S/16KS/8.5x11S. Size-Mix: mm, 0: Default, 1: B5S, 2: 16KS, 3: 8.5x11S
710-612 Size-Mix Mode Size Orientation 1 0~1 Switches between LEF and SEF.,0: LEF,1: SEF
710-613 Mixed Size Selection 1 0~1 Switches the size (standard size/non-standard size) to be transmitted from DADF to IISS in mixed
size mode of fax job. 0: Non-standard size mode, 1: Standard size mode
Table 1 DADF
Chain-Link Content Default Range Meaning
Table 2 IISS
Chain-Link Content Default Range Meaning
715-017 IIT Fail Bypass 0 0~1 0: Fail Bypass Off, 1: Fail Bypass On
715-018 Fan Control Mode 0 0~1 0: Normal, 1: Extended mode
715-020 Number of APS 1 0~1 0: 1 APS, 1: 2 APS
715-022 Lamp Fan Fail Bypass 0 0~1 On/Off of Lamp Fan Fail Detection. 0: On, 1: Off
715-023 Lamp Fan On Time (Low Rotation) 15 0~60 Time period to operate Lamp Fan at low rotation (value can be set in 1-minute increments)
715-024 Lamp Fan Off Time 0 0~60 Time period during which Lamp Fan stops (value can be set in 1-minute increments)
715-025 FL Timer Set 0 0~1 0: Standard FL Timer settings (30min rest/0.5sec On), 1: Condensation mode setting (Diag 715-
026, 715-027 timer settings apply)
715-026 Lamp ON Interval 30 1~60 Interval setting (time between Lamp OFF and Lamp ON again) (unit: min.)
715-027 Lamp ON Time 1 1~60 Lamp ON time setting (unit: sec.)
715-030 IIT Failure Part Diagnosis 0 0-65535 By writing 1, diagnosis for IIT failed part starts. The numbers of failed parts that are predicted to read
this NVM are displayed after the failed parts diagnosis ends. When Fail occurs during the failed
parts diagnosis, Fail code is recorded in this NVM and the failed parts diagnosis ends. Even when 1
is entered, the value is not actually written. When values other than 1 are entered, the values are
invalid.
715-050 Platen SS Registration Adjustment 100 16~184 Slow Scan Direction Regi Correction Value (0.036mm/increment), Factory Settings
715-051 Platen SS Reduce/Enlarge Adjustment 50 44~56 Slow Scan Direction Regi Correction Value (0.1%/increment), Factory Settings
715-052 Platen Glass Type 2 0~2 0: Platen model, 1: Belt DADF, 2: CVT, Factory Settings
715-053 Platen PRadjF 120 0~240 Fast Scan Direction Regi Correction Value (Dot), VLSS=PROMVLSS+(PRadjF-120)x2, Factory Set-
tings
715-056 CVT FS Offset Side1-1 (139.7-148) 120 0~240 Fast Scan Direction Regi Correction Value (2dot/increment) in CVT. Factory Settings
715-057 CVT FS Offset Rear Side2-1 (139.7~148) 120 0~240 Fast Scan Direction Regi Correction Value (2dot/increment) in CVT. Factory Settings
715-058 CVT FS Offset Side1-2 (182-194) 120 0~240 Fast Scan Direction Regi Correction Value (2dot/increment) in CVT. Factory Settings
715-059 CVT FS Offset Side2-2 (182-194) 120 0~240 Fast Scan Direction Regi Correction Value (2dot/increment) in CVT. Factory Settings
715-060 CVT FS Offset Side1-3 (203.2) 120 0~240 Fast Scan Direction Regi Correction Value (2dot/increment) in CVT. Factory Settings
715-061 CVT FS Offset Side2-3 (203.2) 120 0~240 Fast Scan Direction Regi Correction Value (2dot/increment) in CVT. Factory Settings
715-062 CVT FS Offset Side1-4 (210) 120 0~240 Fast Scan Direction Regi Correction Value (2dot/increment) in CVT. Factory Settings
715-063 CVT FS Offset Side2-4 (210) 120 0~240 Fast Scan Direction Regi Correction Value (2dot/increment) in CVT. Factory Settings
