February, 2008
6-42
WorkCentre 5225, 5230
IIT NVM List
Launch Version
General Procedures
Chain 719-xxx Configuration
715-819 Lamp Fan Fail (Since Reset) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-820 CCD Fan Fail (Overall Total) 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-821 CCD Fan Fail (Since Reset) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-822 AGC Fail (Overall Total) 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-823 AGC Fail (Since Reset) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-824 AOC Fail (Overall Total) 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-825 AOC Fail (Since Reset) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-826 IPS PWBA Fail (Overall Total) 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-827 IPS PWBA Fail (Since Reset) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-828 IISS/EXT Communication Fail (Overall Total) 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-829 IISS/EXT Communication Fail (Since Reset) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-830 Extension EEPROM Fail (Overall Total) 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-831 Extension EEPROM Fail (Since Reset) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-832 IPS-EXT Connection Fail (Overall Total) 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-833 IPS-EXT Connection Fail (Since Reset) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-834 IPS-YATA Connection Fail (Overall Total) 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-835 IPS-YATA Connection Fail (Since Reset) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-836 EXT-YATA Connection Fail (Overall Total) 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-837 EXT-YATA Connection Fail (Since Reset) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-838 YATA PWBA Fail (Overall Total) 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-839 YATA PWBA Fail (Since Reset) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-840 ITS PWBA Memory Fail (Overall Total) 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-841 ITS PWBA Memory Fail (Since Reset) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-856 IIT Hot Line Fail (Overall Total) 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-857 IIT Hot Line Fail (Since Reset) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-860 Scan Replacement Life Count (upper digits) 91 0~65535 Scan Replacement Life Count (upper digits) (write not permitted): 6,000,000 times (including Pre
Scan)
715-861 Scan Replacement Life Count (lower digits) 36224 0~65535 Scan Replacement Life Count (lower digits) (write not permitted): 6,000,000 times (including Pre
Scan)
715-875 Lamp On Time Replacement Life Count (upper
digits)
109 0~65535 Lamp On Time Replacement Life Count (upper digits) (write not permitted): 7,200,000 sec. (2,000
hr.)
715-876 Lamp On Time Replacement Life Count (lower
digits)
56576 0~65535 Lamp On Time Replacement Life Count (lower digits) (write not permitted): 7,200,000 sec. (2,000
hr.)
715-890 Lamp On Replacement Life Count (upper digits) 91 0~65535 Lamp On Replacement Life Count (upper digits) (write not permitted): 6,000,000 times
715-891 Lamp On Replacement Life Count (lower digits) 36224 0~65535 Lamp On Replacement Life Count (lower digits) (write not permitted): 6,000,000 times
Table 2 IISS
Chain-Link Content Default Range Meaning
