6-41
WorkCentre 5225, 5230
IIT NVM List
General Procedures
Launch Version
715-720 Normal Density Text (BW Copy) 128 0~256 B/W COPY Text Normal Density Adjustment
715-721 High Density Text (BW Copy) 128 0~256 B/W COPY Text Darker 3 Density Adjustment
715-722 Normal Density Text (Scan/Fax) 128 0~256 Scan/FAX Text Normal Density Adjustment
715-723 High Density Text (Scan/Fax) 128 0~256 Scan/FAX Text Darker 3 Density Adjustment
715-724 PLTN RAE SS Not Detect Area 0 0~65535 Slow Scan Non-detection area Setup Value at Real Time AE for Platen model. BASE, HAEST,
MAESST, NAESS
715-725 DADF-P-Job RAE SS Not Detect Area 0 0~65535 Slow Scan Non-detection area Setup Value at Real Time AE for DADF model Platen job. Or, Slow
Scan Non-detection area Setup Value at Real Time AE for CVT job. BASE, HAEST, MAESST,
NAESS
715-726 DADF-D-Job RAE SS Not Detect Area 0 0~65535 Slow Scan Non-detection area Setup Value at Real Time AE for DADF model DADF job. BASE,
HAEST, MAESST, NAESS
715-780 B-Hue Start Degree 270 0~360 The value can be set in 1 degree (C) increments
715-781 B-Hue End Degree 320 0~360 The value can be set in 1 degree (C) increments
715-782 G-Hue Start Degree 110 0~360 The value can be set in 1 degree (C) increments
715-783 G-Hue End Degree 200 0~360 The value can be set in 1 degree (C) increments
715-784 R-Hue Start Degree 350 0~360 The value can be set in 1 degree (C) increments
715-785 R-Hue End Degree 60 0~360 The value can be set in 1 degree (C) increments
715-786 Y-Hue Start Degree 60 0~360 The value can be set in 1 degree (C) increments
715-787 Y-Hue End Degree 120 0~360 The value can be set in 1 degree (C) increments
715-788 M-Hue Start Degree 320 0~360 The value can be set in 1 degree (C) increments
715-789 M-Hue End Degree 10 0~360 The value can be set in 1 degree (C) increments
715-790 C-Hue Start Degree 190 0~360 The value can be set in 1 degree (C) increments
715-791 C-Hue End Degree 280 0~360 The value can be set in 1 degree (C) increments
715-800 IISS-DADF Communication Fail (Overall Total) 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-801 IISS-DADF Communication Fail (Since Reset) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-802 IISS-Controller Communication Fail (Overall
Tot al)
0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-803 IISS-Controller Communication Fail (Since Reset) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-804 DADF EEPROM Fail (Overall Total) 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-805 DADF EEPROM Fail (Since Reset) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-806 IPS Fan Failure Count (Overall Total) 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-807 IPS Fan Failure Count (Since Reset) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-808 CRG Position Fail (Overall Total) 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-809 CRG Position Fail (Since Reset) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-810 IISS LOGIC Fail (Overall Total) 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-811 IISS LOGIC Fail (Since Reset) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-814 Lamp Illumination Fail (Overall Total) 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-815 Lamp Illumination Fail (Since Reset) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-816 CRG Over Run Fail (Overall Total) 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-817 CRG Over Run Fail (Since Reset) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-818 Lamp Fan Fail (Overall Total) 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
Table 2 IISS
Chain-Link Content Default Range Meaning
