Xerox WorkCentre 5230 User Manual

February, 2008
6-63
WorkCentre 5225, 5230
General Procedures
Launch Version
770-116 IP Address Null Valid only in the case of IPv4 Protocol. Entry is possible in IPv4 literal format. The character
string shall be null-terminated. Restrictions: only 0 to 9 and dots (.) can be used.
770-117 Subnet Mask Null Valid only in the case of IPv4 Protocol. Entry is possible in IPv4 literal format. The character
string shall be null-terminated. Restrictions: only 0 to 9 and dots (.) can be used.
770-118 WINS Server Address 1 Null Valid only in the case of IPv4 Protocol. Entry is possible in IPv4 literal format. The character
string shall be null-terminated. Restrictions: only 0 to 9 and dots (.) used in the address as
separators can be used.
770-119 WINS Server Address 2 Null Valid only in the case of IPv4 Protocol. Entry is possible in IPv4 literal format. The character
string shall be null-terminated. Restrictions: only 0 to 9 and dots (.) used in the address as
separators can be used.
770-120 WINS Auto Config DHCP 0x10: Manual setting, 0x02: DHCP
770-122 Gateway Address Null Valid only in the case of IPv4 Protocol. Entry is possible in IPv4 literal format. The character
string shall be null-terminated. Restrictions: only 0 to 9 and dots (.) can be used.
770-126 IPv6 Validate Flag for Manual Configuration 0 0~1 0: Disable this function, 1: Enable this function
770-127 IPv6 Address Prefix Length for Manual
Configuration
0 0~128 0 to 128 bits
770-128 IPv6 Address for Manual Configuration Null Indicates IPv6 address in (null-terminated) literal format
770-129 IPv6 Gateway Address for Manual Configu-
ration
Null Indicates IPv6 address in (null-terminated) literal format
770-130 Agent Port Enable 1: Enable 0~1 0: Disable, 1: Enable
770-131 Agent Transport Flag 2: UDP 0~3 0: Both Off, 1: IPX, 2: UDP, 3: Both On
770-133 Agent Community Name 1 ~ 10 NULL (Replace with
“fxSystemMgr” on the
PDU)
JISX0201 character code (12 characters)
770-135 lpd Valid IP Address 1 Null IPv4 address in (null-terminated) literal format will be stored. Default is null.
770-136 lpd Valid IP Address 2 Null IPv4 address in (null-terminated) literal format will be stored. Default is null.
770-137 lpd Valid IP Address 3 Null IPv4 address in (null-terminated) literal format will be stored. Default is null.
770-138 lpd Valid IP Address 4 Null IPv4 address in (null-terminated) literal format will be stored. Default is null.
770-139 lpd Valid IP Address 5 Null IPv4 address in (null-terminated) literal format will be stored. Default is null.
770-140 EWS Port Enable 1: Enable 0~1 0: Disable, 1: Enable
770-151 IPv6 Access Control 0 0~1 0: Disable access control, 1: Enable access control
770-152 IPv6 Address 1 for Auto Configuration Null Indicates IPv6 address in (null-terminated) literal format
770-153 IPv6 Address 2 for Auto Configuration Null Indicates IPv6 address in (null-terminated) literal format
770-154 IPv6 Address 3 for Auto Configuration Null Indicates IPv6 address in (null-terminated) literal format
770-155 IPv6 Address 1 Prefix Length for Auto Con-
figuration
0 0~128 0 to 128 bits
770-156 IPv6 Address 2 Prefix Length for Auto Con-
figuration
0 0~128 0 to 128 bits
770-157 IPv6 Address 3 Prefix Length for Auto Con-
figuration
0 0~128 0 to 128 bits
770-158 IPv6 Link Local Address Null Indicates IPv6 address in (null-terminated) literal format
Table 5 I/O Port Protocol
Chain-
Link Content Default Range Meaning

Xerox WorkCentre 5230 Specifications

General

Maximum print size	A3 (297 x 420 mm)
Standard input capacity	500 sheets
Internal memory	No MB
Type	Digital copier
