790-273 Fixed Reduce/Enlarge 1 in Scan XE/DMO-E: 1001 (25%), DMO-W:
1001 (25%), XC: 1001 (25%)
25~1026 1~24: Not in use, 25~400:%, 401~1000: Not in use, 1001: 25.00%, 1002: 35.30%,
1003: 50.00%, 1004: 57.70%, 1005: 61.20%, 1006: 64.70%, 1007: 70.70%, 1008:
78.50%, 1009: 81.60%, 1010: 86.60%, 1011: 94.00%, 1012: 97.30%, 1013:
115.40%, 1014: 122.50%, 1015: 127.30%, 1016: 129.40%, 1017: 141.40%, 1018:
154.50%, 1019: 163.20%, 1020: 173.20%, 1021: 180.00%, 1022: 200.00%, 1023:
220.00%, 1024: 282.80%, 1025: 400.00%, 1026: 300.00%
790-274 Fixed Reduce/Enlarge 2 in Scan XE/DMO-E: 1003 (50%), DMO-W:
1003 (50%), XC: 1003 (50%)
25~1026 Same as above
790-275 Fixed Reduce/Enlarge 3 in Scan XE/DMO-E: 1006 (64.7%), DMO-W:
1006 (64.7%), XC: 1006 (64.7%)
25~1026 Same as above
790-276 Fixed Reduce/Enlarge 4 in Scan XE/DMO-E: 1007 (70.7%), DMO-W:
1007 (70.7%), XC: 1007 (70.7%)
25~1026 Same as above
790-277 Fixed Reduce/Enlarge 5 in Scan XE/DMO-E: 1008 (78.5%), DMO-W:
1008 (78.5%), XC: 1008 (78.5%)
25~1026 Same as above
790-278 Fixed Reduce/Enlarge 6 in Scan XE/DMO-E: 1011 (94%), DMO-W:
1011 (94%), XC: 1011 (94%)
25~1026 Same as above
790-279 Fixed Reduce/Enlarge 7 in Scan XE/DMO-E: 1012 (97.3%), DMO-W:
1012 (97.3%), XC: 1012 (129.4%)
25~1026 Same as above
790-280 Output Size 1 in Scan XE/DMO-E: 10 (A3SEF), DMO-W: 10
(A3SEF), XC: 89 (8.5x11LEF)
1~255 1: Not defined, 10: A3SEF, 11: A4LEF, 12:A4SEF, 13: A5LEF, 14: A5SEF, 15:
A6LEF, 16: A6SEF, 50: C4 Envelope SEF, 51: C5 Envelope SEF, 55: DL Envelope
LEF, 66: B4SEF, 67: B5LEF, 68: B5SEF, 69: B6LEF, 70: B6SEF, 80: 11x17SEF, 87:
PostcardLEF, 88: PostcardSEF, 89: 8.5x11LEF, 90: 8.5x11SEF, 92: 8.5x14SEF, 94:
12x18SEF, 98: 12x19SEF, 101: 16K LEF, 102: 16K SEF, 104: 8K SEF, 105: Post
-
card (3.5x5.5) LEF, 106: Postcard (3.5x5.5) SEF, 107: Postcard (4x6) LEF, 108:
Postcard (4x6) SEF, 109: Postcard (5x7) LEF, 110: Postcard (5x7) SEF, 111:
5.5x8.5LEF, 112: 5.5x8.5SEF, 113: Postcard (6x9) LEF, 114: Postcard (6x9) SEF,
115: 8x10LEF, 116: 8x10SEF, 118: 8.5x13SEF, 119: 7.25x10.5LEF, 120:
7.25x10.5SEF, 123: Youkei 0 LEF, 124: Choukei 3 SEF, 126: Choukei 4 SEF, 132:
11x15SEF, 135: Photo L LEF, 136: Photo L SEF, 137: Commercial 10 LEF, 139:
215x315mm (8.46x12.4) SEF, 141: SRA3 SEF, 142: Special A3SEF, 143: Special
A4LEF, 144: Special A4SEF, 145: A4 Cover SEF, 146: A4 Cover LEF, 147:
13x19SEF, 148: 13x18SEF, 149: 12.6x19.2SEF, 150: Letter Cover (9x11) SEF, 151:
Letter Cover (9x11) LEF, 152: Monarch Envelope LEF, 154: Prepaid Postcard LEF,
155: Prepaid Postcard SEF, 156: 16K LEF (GCO), 157: 16K SEF (GCO), 159: 8K
SEF (GCO)
790-281 Output Size 2 in Scan XE/DMO-E: 12 (A4SEF), DMO-W: 12
(A4SEF), XC: 90 (8.5x11SEF)
1~255 Same as above
790-282 Output Size 3 in Scan XE/DMO-E: 11 (A4LEF), DMO-W: 11
(A4LEF), XC: 118 (8.5x13SEF)
1~255 Same as above
790-283 Output Size 4 in Scan XE/DMO-E: 14 (A5SEF), DMO-W: 14
(A5SEF), XC: 92 (8.5x14SEF)
1~255 Same as above
790-284 Output Size 5 in Scan XE/DMO-E: 15 (A5LEF), DMO-W: 15
(A5LEF), XC: 132 (11x15SEF)
1~255 Same as above
790-285 Output Size 6 in Scan XE/DMO-E: 66 (B4SEF), DMO-W: 66
(B4SEF), XC: 80 (11x17SEF)
1~255 Same as above
Table 9 UI
Chain-
Link Content Default Range Meaning
