Xerox WorkCentre 5230

February, 2008
6-104
WorkCentre 5225, 5230
Launch Version
General Procedures
825-226 G3 RX Modem Speed for Ch5 on V.34 14 1~14 1 to 14. 1: 2400bps, 2: 4800bps, 3: 7200bps, 4: 9600bps, 5: 12000bps, 6: 14400bps, 7:
16800bps, 8: 19200bps, 9: 21600bps, 10: 24000bps, 11: 26400bps, 12: 28800bps, 13:
31200bps, 14: 33600bps
825-227 G3 TX Modem MAX Speed for Ch0 except
V.34
8 1~8 1 to 8. 1: 2400bps/V.27ter, 2: 4800bps/V.27ter, 3: 7200bps/V.29, 4: 9600bps/V.29, 5:
7200bps/V.17, 6: 9600bps/V.17, 7: 12000bps/V.17, 8: 14400bps/V.17
825-228 G3 TX Modem MAX Speed for Ch1 except
V.34
8 1~8 1 to 8. 1: 2400bps/V.27ter, 2: 4800bps/V.27ter, 3: 7200bps/V.29, 4: 9600bps/V.29, 5:
7200bps/V.17, 6: 9600bps/V.17, 7: 12000bps/V.17, 8: 14400bps/V.17
825-229 G3 TX Modem MAX Speed for Ch2 except
V.34
8 1~8 1 to 8. 1: 2400bps/V.27ter, 2: 4800bps/V.27ter, 3: 7200bps/V.29, 4: 9600bps/V.29, 5:
7200bps/V.17, 6: 9600bps/V.17, 7: 12000bps/V.17, 8: 14400bps/V.17
825-230 G3 TX Modem MAX Speed for Ch3 except
V.34
8 1~8 1 to 8. 1: 2400bps/V.27ter, 2: 4800bps/V.27ter, 3: 7200bps/V.29, 4: 9600bps/V.29, 5:
7200bps/V.17, 6: 9600bps/V.17, 7: 12000bps/V.17, 8: 14400bps/V.17
825-231 G3 TX Modem MAX Speed for Ch4 except
V.34
8 1~8 1 to 8. 1: 2400bps/V.27ter, 2: 4800bps/V.27ter, 3: 7200bps/V.29, 4: 9600bps/V.29, 5:
7200bps/V.17, 6: 9600bps/V.17, 7: 12000bps/V.17, 8: 14400bps/V.17
825-232 G3 TX Modem MAX Speed for Ch5 except
V.34
8 1~8 1 to 8. 1: 2400bps/V.27ter, 2: 4800bps/V.27ter, 3: 7200bps/V.29, 4: 9600bps/V.29, 5:
7200bps/V.17, 6: 9600bps/V.17, 7: 12000bps/V.17, 8: 14400bps/V.17
825-233 G3 TX Modem MAX Speed for Ch0 except
V.34 Overseas
2 1~8 1 to 8. 1: 2400bps/V.27ter, 2: 4800bps/V.27ter, 3: 7200bps/V.29, 4: 9600bps/V.29, 5:
7200bps/V.17, 6: 9600bps/V.17, 7: 12000bps/V.17, 8: 14400bps/V.17
825-234 G3 TX Modem MAX Speed for Ch1 except
V.34 Overseas
2 1~8 1 to 8. 1: 2400bps/V.27ter, 2: 4800bps/V.27ter, 3: 7200bps/V.29, 4: 9600bps/V.29, 5:
7200bps/V.17, 6: 9600bps/V.17, 7: 12000bps/V.17, 8: 14400bps/V.17
825-235 G3 TX Modem MAX Speed for Ch2 except
V.34 Overseas
2 1~8 1 to 8. 1: 2400bps/V.27ter, 2: 4800bps/V.27ter, 3: 7200bps/V.29, 4: 9600bps/V.29, 5:
7200bps/V.17, 6: 9600bps/V.17, 7: 12000bps/V.17, 8: 14400bps/V.17
825-236 G3 TX Modem MAX Speed for Ch3 except
V.34 Overseas
2 1~8 1 to 8. 1: 2400bps/V.27ter, 2: 4800bps/V.27ter, 3: 7200bps/V.29, 4: 9600bps/V.29, 5:
7200bps/V.17, 6: 9600bps/V.17, 7: 12000bps/V.17, 8: 14400bps/V.17
825-237 G3 TX Modem MAX Speed for Ch4 except
V.34 Overseas
2 1~8 1 to 8. 1: 2400bps/V.27ter, 2: 4800bps/V.27ter, 3: 7200bps/V.29, 4: 9600bps/V.29, 5:
7200bps/V.17, 6: 9600bps/V.17, 7: 12000bps/V.17, 8: 14400bps/V.17
825-238 G3 TX Modem MAX Speed for Ch5 except
V.34 Overseas
2 1~8 1 to 8. 1: 2400bps/V.27ter, 2: 4800bps/V.27ter, 3: 7200bps/V.29, 4: 9600bps/V.29, 5:
7200bps/V.17, 6: 9600bps/V.17, 7: 12000bps/V.17, 8: 14400bps/V.17
825-239 G3 TX Modem MAX Speed for Ch0 on V.34 14 1~14 1 to 14. 1: 2400bps, 2: 4800bps, 3: 7200bps, 4: 9600bps, 5: 12000bps, 6: 14400bps, 7:
16800bps, 8: 19200bps, 9: 21600bps, 10: 24000bps, 11: 26400bps, 12: 28800bps, 13:
31200bps, 14: 33600bps
825-240 G3 TX Modem MAX Speed for Ch1 on V.34 14 1~14 1 to 14. 1: 2400bps, 2: 4800bps, 3: 7200bps, 4: 9600bps, 5: 12000bps, 6: 14400bps, 7:
16800bps, 8: 19200bps, 9: 21600bps, 10: 24000bps, 11: 26400bps, 12: 28800bps, 13:
31200bps, 14: 33600bps
825-241 G3 TX Modem MAX Speed for Ch2 on V.34 14 1~14 1 to 14. 1: 2400bps, 2: 4800bps, 3: 7200bps, 4: 9600bps, 5: 12000bps, 6: 14400bps, 7:
16800bps, 8: 19200bps, 9: 21600bps, 10: 24000bps, 11: 26400bps, 12: 28800bps, 13:
31200bps, 14: 33600bps
825-242 G3 TX Modem MAX Speed for Ch3 on V.34 14 1~14 1 to 14. 1: 2400bps, 2: 4800bps, 3: 7200bps, 4: 9600bps, 5: 12000bps, 6: 14400bps, 7:
16800bps, 8: 19200bps, 9: 21600bps, 10: 24000bps, 11: 26400bps, 12: 28800bps, 13:
31200bps, 14: 33600bps
825-243 G3 TX Modem MAX Speed for Ch4 on V.34 14 1~14 1 to 14. 1: 2400bps, 2: 4800bps, 3: 7200bps, 4: 9600bps, 5: 12000bps, 6: 14400bps, 7:
16800bps, 8: 19200bps, 9: 21600bps, 10: 24000bps, 11: 26400bps, 12: 28800bps, 13:
31200bps, 14: 33600bps
Table 12 FAX Service
Chain-
Link Content Default Range Meaning
