February, 2008
6-111
WorkCentre 5225, 5230
General Procedures
Launch Version
870-204 UI Diag Parameters Media Type 0: Plain 0~79 [0: Plain, 1: Recycled, 2: Bond, 3: Lightweight, 4: Heavyweight 1, 5: Heavyweight 2, 6:
Heavyweight 1 (Side 2), 7: Heavyweight 2 (Side 2), 8: Extra Heavyweight, 9: Extra Heavy
-
weight (Side 2), 10: Transparency, 11: Adhesive, 12: Labels, 13~31: Plain A~S, 32: Heavy-
weight 1A, 33: Heavyweight 1B, 34: Heavyweight 1S, 35: Heavyweight 1(S2)A, 36:
Heavyweight 1(S2)B, 37: Heavyweight 1(S2)S, 38: Heavyweight 2A, 39: Heavyweight 2B,
40: Heavyweight 2S, 41: Heavyweight 2(S2)A, 42: Heavyweight 2(S2)B, 43: Heavyweight
2(S2)S, 44: Heavyweight 1C, 45: Heavyweight 1C(2S), 46: Heavyweight 2C, 47: Heavy
-
weight 2C(2S), 48: Heavyweight 2D, 49: Heavyweight 2D(2S), 50: Coated 1, 51: Coated
1(S2), 52: Coated 2, 53: Coated 2(S2), 54: Coated 1 Special (Coated Paper), 55~59: Cus
-
tom Paper 1~5, 60: Tracing Paper, 61: Copied Paper, 62: Tabbed Paper Heavyweight 1, 63:
Tabbed Paper Heavyweight 2, 64: Labels 1, 65: Labels 2, 66: Hole-Punched, 67: Plain
paper S1, 68: Plain paper S2, 69: Recycled paper (Recycled paper A), 70: Recycled paper
(Recycled paper B), 71: Heavyweight paper 1S1, 72: Heavyweight paper 1S2, 73: Heavy
-
weight paper 2E, 74: Heavyweight paper 2S1, 75: Heavyweight paper 2S2, 76: Tabbed
sheet 1, 77: Tabbed sheet 2, 78: Coated paper 1A, 79: Coated paper 1B]
870-205 UI Diag Parameters Color Mode 0: 4-color mode 0~3 [0: 4-color mode, 1: Tri-color mode, 2: Monochrome, 3: BW]
870-206 UI Diag Parameters Single Color 0: Black 0~6 [0: Black, 1: Yellow, 2: Magenta, 3: Cyan, 4: Red, 5: Green, 6: Blue]
870-207 UI Diag Parameters Screen 0: Text 0~11 [0: Text, 1: Photo, 2: Binary ED, 3: 24ED, 4: 300DACS, 5: 600, 6: 300, 7: 200C, 8: 200R, 9:
150, 10: Fine, 11: 106 lines]
870-208 UI Diag Parameters LUT 3 0~3 [0: All Off, 1: IOT On, 2: Ctrack On, 3: IOT and Ctrack On]
870-209 UI Diag Parameters Coverage 0: 0% 0~100 [0~100%]
870-210 UI Diag Parameters Resolution 0: 1200x1200 0~4 [0: 1200x1200, 1: 1200x600, 2: 600x600, 3: 300x300, 4: Not used]
870-211 UI Diag Parameters Media Size 5: A4LEF 0~50 [0: A6SEF, 1: A6LEF, 2: A5SEF, 3: A5LEF, 4: A4SEF, 5: A4LEF, 6: A3SEF, 7: B6SEF, 8:
B6LEF, 9: B5SEF, 10: B5LEF, 11: B4SEF, 12: 5.5x8.5(Statement)SEF, 13: 5.5x8.5(State
-
ment)LEF, 14: 7.25x10.5(Executive)SEF, 15: 7.25x10.5(Executive)LEF, 16: 8x10SEF, 17:
8x10LEF, 18: LetterSEF, 19: LetterLEF, 20: 8.46x12.4(Spanish)SEF, 21:
8.5x13(Legal13)SEF, 22: 8.5x14 (Legal14)SEF, 23: 11x15SEF, 24: 11x17(Ledger)SEF, 25:
A4CoverLEF, 26: 9x11 (LetterCover)LEF, 27: 12.0x18.0SEF, 28: 12.6x17.7(SRA3)SEF, 29:
12.6x19.2SEF, 30: 13x18SEF, 31: 13x19SEF, 32: 16K(TFX)SEF, 33: 16K(TFX)LEF, 34:
8K(TFX)SEF, 35: 16K(GCO)SEF, 36: 16K(GCO)LEF, 37: 8K(GCO)SEF, 38: Postcard SEF,
39: Postcard LEF, 40: Prepaid Postcard SEF, 41: Postcard(4x6)SEF, 42: Postcard(4x6)LEF,
43: Postcard(5x7)SEF, 44: Choukei 3SEF, 45: Choukei 3LEF, 46: Commercial 10LEF, 47:
Monarch LEF, 48: DL LEF, 49: Kakukei 20SEF, 50: Kakukei 6LEF]
880-001 ESR Poolserver Config Enable 0 0~1 0: Disable, 1: Enable
880-002 ESR Poolserver Config Port No. 80 1~65535 1 to 65535
880-003 ESR Poolserver Config Schema 1 1~2 1: HTTP, 2: HTTPS
880-004 ESR Poolserver Config Use Static Auth
Info
0 0~1 0: Disable, 1: Enable
880-005 ESR Poolserver Config Timeout 60 1~300 1 to 300
880-006 Default Job Flow Repository 0 0~1 0: Device, 1: Pool server
880-007 Job Flow Search Keyword 1 Null For MN market, maximum of 12 ASCII characters. For Japan, maximum of 6 two-byte char-
acters of alpha numerics, symbols, Katakana, Hiraganas, and Kanji.
880-008 Job Flow Search Keyword 2 Null For MN market, maximum of 12 ASCII characters. For Japan, maximum of 6 two-byte char-
acters of alpha numerics, symbols, Katakana, Hiraganas, and Kanji.
Table 16 Diag
