Xerox WorkCentre 5230 User Manual

February, 2008
6-110
WorkCentre 5225, 5230
Launch Version
General Procedures
870-025 XERO:#3DRUM AC CYCLE previous value - [0~99999999]
870-026 XERO:#4DRUM AC CYCLE previous value - [0~99999999]
870-027 Xfer:IBT Belt(IMPS) previous value - [0~99999999]
870-028 Xfer:IBT Belt(CYCLE) previous value - [0~99999999]
870-029 Xfer:1st BTR previous value - [0~99999999]
870-030 Xfer:Back Up Roll previous value - [0~99999999]
870-031 Xfer:2nd BTR Unit previous value - [0~99999999]
870-032 Xfer:Bearing BTR previous value - [0~99999999]
870-033 Xfer:Trim within Transfer Module previous
value
- [0~99999999]
870-034 Xfer:Belt Cleaner Blade previous value - [0~99999999]
870-035 Xfer:Belt Cleaner Film Seal previous value - [0~99999999]
870-036 PH:1Tray NMBR of Feeds previous value - [0~99999999]
870-037 PH:MSI NMBR of Feeds previous value - [0~99999999]
870-038 PH:3TM 2Tray NMBR of Feeds previous
value
- [0~99999999]
870-039 PH:3TM 3Tray NMBR of Feeds previous
value
- [0~99999999]
870-040 PH:3TM 4Tray NMBR of Feeds previous
value
- [0~99999999]
870-041 PH:1TM 2Tray NMBR of Feeds previous
value
- [0~99999999]
870-042 PH:TTM 2Tray NMBR of Feeds previous
value
- [0~99999999]
870-043 PH:TTM 3Tray NMBR of Feeds previous
value
- [0~99999999]
870-044 PH:TTM 4Tray NMBR of Feeds previous
value
- [0~99999999]
870-045 PV(CV) Counter for FILTER Life previous
value
- [0~99999999]
870-200 UI Diag Parameters Input Tray 1: Tray 1 0~9 [0: Auto, 1: Tray 1, 2: Tray 2, 3: Tray 3, 4: Tray 4, 5: Tray 5, 6: SMH, 7: HCF1, 8: HCF2, 9:
Interposer
870-202 UI Diag Parameters Total Sets In Job 1: 1 set 1~999 [1~999 sets]
870-203 UI Diag Parameters Paper Plex 0: 1 Sided 0~2 [0: 1 Sided, 1: 2: 2 Sided (H to H), 2: 2: 2 Sided (H to T)]
Table 16 Diag
Chain-
Link Content Default Range Meaning

Xerox WorkCentre 5230 Specifications

General

Maximum print size	A3 (297 x 420 mm)
Standard input capacity	500 sheets
Internal memory	No MB
Type	Digital copier
