Xerox WorkCentre 5230 User Manual

February, 2008
6-133
WorkCentre 5225, 5230
Component Control
General Procedures
Launch Version
005-028 CVT-DADF Reg.Motor(Speed3) - ON for 50sec -> Auto OFF O 005-026~005-027
005-029~005-036
Not Available
005-029 CVT-DADF Reg.Motor(Speed4) - ON for 50sec -> Auto OFF O 005-026~005-028
005-030~005-036
Not Available
005-030 CVT-DADF Reg.Motor(Speed5) - ON for 50sec -> Auto OFF O 005-026~005-029
005-031~005-036
Not Available
005-031 CVT-DADF Reg.Motor(Speed6) - ON for 50sec -> Auto OFF O 005-026~005-030
005-032~005-036
Not Available
005-032 CVT-DADF Reg.Motor(Speed7) - ON for 50sec -> Auto OFF O 005-026~005-031
005-033~005-036
Not Available
005-033 CVT-DADF Reg.Motor(Speed8) - ON for 50sec -> Auto OFF O 005-026~005-032
005-034~005-036
Not Available
005-034 CVT-DADF Reg.Motor(Speed9) - ON for 50sec -> Auto OFF O 005-026~005-033
005-035~005-036
Not Available
005-036 CVT-DADF Reg.Motor(Reverse) - ON for 50sec -> Auto OFF O 005-026~005-036 Not Available
005-072 CVT Nip Release Solenoid L 3sec on O - Not Available
005-073 CVT Stamp Solenoid L ON for 10msec -> Auto
OFF
O - Not Available
005-083 Doc Ready L Turn ON the Doc Ready
signal.
X - Not Available
005-084 Doc Set LED L Belt: Turn ON the DOC
SET LED
X(Belt)
O(CVT)
- Not Available
005-088 Image Area H ON for 5sec O - Not Available
005-090 Nudger initialize - Performs Nudger Roll ini-
tialization.
O - Not Available
062-002 IIT Exposure Lamp L Turn the Lamp ON for
180sec -> Auto OFF
O - Turn it OFF when Stop command is
received before Auto OFF.
062-005 IIT Scan Motor (Scan) Each has 4 phases.
H/L Switching
Move it 50mm from cur-
rent position in Scan
direction -> Auto OFF
O 062-006 Stop command is not accepted before
Auto OFF.
062-006 IIT Scan Motor (Return) Each has 4 phases.
H/L Switching
Move it 50mm from cur-
rent position in Return
direction -> Auto OFF
O 062-005 Stop command is not accepted before
Auto OFF.
062-086 IIT Image Area (Differential) H IMAGE-AREA Signal Out-
put
X - Not Available
062-091 Exchange To ADF L Turn ON the document
exchange command sig
-
nal to the DADF
X - Not Available
Table 4 Output Component Control Codes IIT
Chain-Link Name Connector Level Meaning Timer Off
Multiple Output
Prohibited Items Remarks
