WorkCentre 5225, 5230
Component Control
Launch Version
General Procedures
005-221 CVT-DADF Tray Size SNR Number1 L paper detected by Tray Size SNR Number1 Not Available
005-222 CVT-DADF Tray Size SNR Number2 L paper detected by Tray Size SNR Number2 Not Available
005-224 Scan Start H Scan Start Signal ON Not Available
005-225 Nudger Position Snr H The Nudger Roll is at UP position. Not Available
062-201 Sheet Abort L Document Regist Not Available
062-212 IIT Regi Sensor L De-actuation of Regi Sensor Not Available
062-240 ADF Exist H DADF is not installed Not Available
062-251 APS Sensor1 APS SNR1:L APS ON: H Document detected Not Available
062-253 APS Sensor3 APS SNR3:L APS ON: H Document detected Not Available
062-272 Scan Start L Scan available Not Available
062-300 Platen I/L Switch L Platen closed Not Available
062-301 Angle Sensor L Platen opened Not Available
Table 4 Output Component Control Codes IIT
Chain-Link Name Connector Level Meaning Timer Off
Multiple Output
Prohibited Items
Remarks
005-001 CVT-DADF Feed Motor(Speed1) - ON for 50sec -> Auto OFF O 005-002~005-014 Not Available
005-002 CVT-DADF Feed Motor(Speed2) - ON for 50sec -> Auto OFF O 005-001
005-003~005-014
Not Available
005-003 CVT-DADF Feed Motor(Speed3) - ON for 50sec -> Auto OFF O 005-001~005-002
005-004~005-014
Not Available
005-004 CVT-DADF Feed Motor(Speed4) - ON for 50sec -> Auto OFF O 005-001~005-003
005-005~005-014
Not Available
005-005 CVT-DADF Feed Motor(Speed5) - ON for 50sec -> Auto OFF O 005-001~005-004
005-006~005-014
Not Available
005-006 CVT-DADF Feed Motor(Speed6) - ON for 50sec -> Auto OFF O 005-001~005-005
005-007~005-014
Not Available
005-007 CVT-DADF Feed Motor(Speed7) - ON for 50sec -> Auto OFF O 005-001~005-006
005-008~005-014
Not Available
005-008 CVT-DADF Feed Motor(Speed8) - ON for 50sec -> Auto OFF O 005-001~005-007
005-009~005-014
Not Available
005-009 CVT-DADF Feed Motor(Speed9) - ON for 50sec -> Auto OFF O 005-001~005-008
005-010~005-014
Not Available
005-010 CVT-DADF Feed Motor(Speed10) - ON for 50sec -> Auto OFF O 005-001~005-009
005-013~005-014
Not Available
005-013 CVT-DADF Feed Motor(Speed11) - ON for 50sec -> Auto OFF O 005-001~005-010
005-014
Not Available
005-014 CVT-DADF Feed Motor(Reverse) - ON for 50sec -> Auto OFF O 005-001~005-013 Not Available
005-026 CVT-DADF Reg.Motor(Speed1) - ON for 50sec -> Auto OFF O 005-027~005-036 Not Available
005-027 CVT-DADF Reg.Motor(Speed2) - ON for 50sec -> Auto OFF O 005-026
005-028~005-036
Not Available
Table 3 Input Component Control Codes IIT
Chain-Link Name Connector Level Meaning Remarks
