Xerox WorkCentre 5230 User Manual

February, 2008
6-131
WorkCentre 5225, 5230
Component Control
General Procedures
Launch Version
091-003 BCR DC BIAS - Same as Name X X The BCR AC, BCR DC, DEVE DC and BTR
output simultaneously. * CF=53-45(CL=751-
560) to 1 (single output) enables indepen
-
dent outputs.
091-004 DTS <- Same as Name X X Not Available
091-005 DRUM MOTOR ON L Same as Name X X The BCR AC, BCR DC, DEVE DC and BTR
output simultaneously. * CF=53-45(CL=751-
560) to 1 (single output) enables indepen
-
dent outputs.
091-006 MAIN MOTOR ON L Same as Name X X Not Available
091-007 Developer DC BIAS - Same as Name X X The BCR AC, BCR DC, DEVE DC and BTR
output simultaneously. * CF=53-45(CL=751-
560) to 1 (single output) enables indepen
-
dent outputs.
091-010 BTR(-) BIAS - Same as Name X X The BCR AC, BCR DC, DEVE DC and BTR
output simultaneously. * CF=53-45(CL=751-
560) to 1 (single output) enables indepen
-
dent outputs.
093-001 Dispense Motor L Same as Name O X The BCR AC, BCR DC, DEVE DC and BTR
output simultaneously. * CF=53-45(CL=751-
560) to 1 (single output) enables indepen
-
dent outputs.
094-001 BTR(+) BIAS - Same as Name X X The BCR AC, BCR DC, DEVE DC and BTR
output simultaneously. * CF=53-45(CL=751-
560) to 1 (single output) enables indepen
-
dent outputs.
Table 3 Input Component Control Codes IIT
Chain-Link Name Connector Level Meaning Remarks
005-102 Document Sensor H No paper detected by Document Sensor Not Available
005-110 Regi Sensor (Belt DADF/CVT) L Paper detected by Regi Sensor Not Available
005-205 CVT-DADF Feed Out Sensor H Paper detected by Feed Out Sensor Not Available
005-206 CVT-DADF Pre-Reg.Sensor H Paper detected by Pre-Reg. Sensor Not Available
005-211 CVT-DADF Invert Sensor H Paper detected by Inverter Sensor Not Available
005-212 CVT-DADF Feeder Cover Interlock
Switch
- Feeder Cover open Not Available
005-213 CVT-DADF Platen Interlock Switch H Platen Interlock open Not Available
005-215 CVT-DADF #1 Tray APS Sensor L Light is not blocked by the actuator Not Available
005-216 CVT-DADF #2 Tray APS Sensor L Light is not blocked by the actuator Not Available
005-217 CVT-DADF #3 Tray APS Sensor L Light is not blocked by the actuator Not Available
005-218 CVT-DADF #1 APS Sensor L paper detected by APS Number1 Sensor Not Available
005-219 CVT-DADF #2 APS Sensor L paper detected by APS Number1 Sensor Not Available
005-220 CVT-DADF #3 APS Sensor L paper detected by APS Number1 Sensor Not Available
Table 2 Output Component Control Codes IOT
Chain-Link Name
Connector
Level Meaning Timer Off Cycle Operation Remarks

Xerox WorkCentre 5230 Specifications

General

Maximum print size	A3 (297 x 420 mm)
Standard input capacity	500 sheets
Internal memory	No MB
Type	Digital copier
