Xerox WorkCentre 5230 User Manual

February, 2008
2-313
WorkCentre 5225, 5230
024-917 (A-Finisher)
Status Indicator Raps
Launch Version
Enter [012-330]. Rotate the Stacker Stack Sensor 1 actuator by hand to block and unblock the
sensor.
The display changes.
YN
Check the connections of P/J8707 and P/J8722. P/J8707 and P/J8722 are securely
connected.
YN
Connect P/J8707 and P/J8722 securely.
Check for an open or short circuit between J8707 and J8722. The wires between
J8707 and J8722 are OK.
YN
Repair the open or short circuit.
Measure the voltage between J8707-6 (+) on the Finisher PWB and GND (-). The volt-
age is approx. +5VDC.
YN
Go to Wirenet A-Finisher +5VDC and check the +5VDC circuit.
Measure the voltage between J8707-5 (+) on the Finisher PWB and GND (-). Rotate the
Stacker Stack Sensor 1 actuator by hand to block and unblock the sensor.
The voltage
changes.
YN
Replace the Stacker Stack Sensor 1 (PL 22.8).
Check the wires and connectors for an intermittent open or short circuit. If the problem
continues, replace the Finisher PWB (PL 22.7).
Enter [012-279]. Rotate the Stacker Stack Sensor 2 actuator by hand to block and unblock the
acceptance surface.
The display of DC330[012-279] changes.
YN
Check the connections of P/J8707 and P/J8721. P/J8707 and P/J8721 are securely
connected.
YN
Connect P/J8707 and P/J8721 securely.
Check for an open wire or short circuit between J8707 and J8721. The wire between
J8707 and J8721 is normally conductive with no open wire or short circuit.
YN
Repair the open wire or short circuit.
Measure the voltage between J8707-3 (+) on the Finisher PWB and GND (-). The volt-
age is approx. +5VDC.
YN
Go to Wirenet A-Finisher +5VDC and check the +5VDC circuit.
Measure the voltage between J8707-2 (+) on the Finisher PWB and GND (-). Rotate the
Stacker Stack Sensor 2 actuator by hand to block and unblock the sensor.
The voltage
changes.
YN
Replace the Stacker Stack Sensor 2 (PL 22.8).
Check the wires and connectors for an intermittent open or short circuit. If the problem
continues, replace the Finisher PWB (PL 22.7).
Enter [012-060] and [012-061] alternately. The Stacker Motor rotates.
YN
Check the connections of P/J8711 and P/J8736. P/J8711 and P/J8736 are securely
connected.
YN
Connect P/J8711 and P/J8736 securely.
Check for an open or short circuit between J8711 and P8736. The wires between
J8711 and P8736 are OK.
YN
Repair the open or short circuit.
Enter [012-060], measure the voltage between J8711-1 (+) on the Finisher PWB and
GND (-).
The voltage changes.
YN
Check the wires and connectors for an intermittent open or short circuit. If the prob-
lem continues, replace the Finisher PWB (PL 22.7).
Enter [012-061], measure the voltage between J8711-2 (+) on the Finisher PWB and
GND (-).
The voltage changes.
YN
Check the wires and connectors for an intermittent open or short circuit. If the prob-
lem continues, replace the Finisher PWB (PL 22.7).
Replace the Stacker Motor (PL 22.8).
Check the connections of the connectors between the Finisher and the IOT. The connectors
are securely connected.
YN
Connect the connectors securely.
If the problem continues, replace the Finisher PWB (PL 22.7).
