3-33
PERIODIC MAINTENANCE
• Outer V-belt case
Refer to “V-BELT AUTOMATIC TRANSMIS-
SION” on page 5-39.
2. Check:
• V-belt
Cracks/damage/wear Replace.
Grease/oil Clean the primary and second-
ary pulleys.
Refer to “V-BELT AUTOMATIC TRANSMIS-
SION” on page 5-39.
Replace the V-belt every 20000 km (12000 mi)
of operation.
3. Install:
• Outer V-belt case
Refer to “V-BELT AUTOMATIC TRANSMIS-
SION” on page 5-39.
• Footboard (right)
• Rear side cowling assembly (right)
• Side cover (right)
• Fuel tank cover assembly
• Center cover
Refer to “GENERAL CHASSIS (2)” on
page 4-11.
• Bottom center cowling
• Side panel
• Bottom side cowling
Refer to “GENERAL CHASSIS (1)” on
page 4-1.
EAS30658
CHECKING THE BRAKE LIGHT SWITCHES
1. Check:
• Front brake light switch operation
• Rear brake light switch operation
When operating the brake lever, confirm that
the brake light comes on.
Faulty Refer to “CHECKING THE
SWITCHES” on page 8-91.
EAS31147
CHECKING AND LUBRICATING THE
CABLES
The following procedure applies to all of the in-
ner and outer cables.
EWA13270
Damaged outer cable may cause the cable to
corrode and interfere with its movement. Re-
place damaged outer cable and inner cables
as soon as possible.
1. Check:
• Outer cable
Damage Replace.
2. Check:
• Cable operation
Rough movement Lubricate.
Hold the cable end upright and pour a few drops
of lubricant into the cable sheath or use a suit-
able lubricating device.
EAS30815
CHECKING THE THROTTLE GRIP
1. Check:
• Throttle cable
Damage/deterioration Replace.
• Throttle cable installation
Incorrect Reinstall the throttle cables.
Refer to “HANDLEBAR” on page 4-74.
2. Check:
• Throttle grip movement
Rough movement Lubricate or replace the
defective part(s).
With the engine stopped, turn the throttle grip
slowly and release it. Make sure that the throttle
grip turns smoothly and returns properly when
released.
Repeat this check with the handlebar turned all
the way to the left and right.
3. Check:
• Throttle grip free play “a”
Out of specification Adjust.
Recommended lubricant
Engine oil or a suitable cable
lubricant
Recommended lubricant
Suitable cable lubricant
Throttle grip free play
1.0–3.0 mm (0.04–0.12 in)
To Next Page
