9-30
ABS (Anti-lock Brake System)
EAS32891
ABS COMPONENTS CHART
5
67
2
8
10
9
1
4
4
3
1. YDT coupler
2. ABS warning light
3. Fuse box (ABS motor fuse, ABS solenoid
fuse, and ABS ECU fuse)
4. ABS ECU
5. Front wheel sensor rotor
6. Front wheel sensor
7. Front brake caliper
8. Rear brake caliper
9. Rear wheel sensor
10. Rear wheel sensor rotor
