8-57
GRIP WARMER SYSTEM (for XP560D)
EAS31008
TROUBLESHOOTING
• Before troubleshooting, remove the following part(s):
1. Front cowling assembly
2. Rear side cowling assembly
3. Leg shield
4. Footboards
The grip warmers do not become warm at all.
1. Check that the MIL is on and that
“Err” is displayed in the multi-func-
tion meter display.
NG
Perform the troubleshooting for DTC No.
U0155. Refer to “U0155 or Err” on page 9-
166.
OK
2. Check that the grip warmers are
not turned off.
NG
Adjust the temperature levels of the grip
warmer settings.
OK
3. Check the fuses.
(Main, ignition, and backup)
Refer to “CHECKING THE FUS-
ES” on page 8-93.
NG Replace the fuse(s).
OK
4. Check the battery.
Refer to “CHECKING AND
CHARGING THE BATTERY” on
page 8-94.
NG
• Clean the battery terminals.
• Recharge or replace the battery.
OK
5. Check the ignition system relay.
Refer to “CHECKING THE RE-
LAYS” on page 8-94.
NG Replace the ignition system relay.
OK
6. Check that the engine is started. NG Start the engine.
OK
7. Check the grip warmers.
Refer to “CHECKING THE GRIP
WARMERS (for XP560D)” on
page 8-109.
NG Replace the grip warmer(s).
OK
8. Check the entire grip warmer sys-
tem wiring.
Refer to “CIRCUIT DIAGRAM” on
page 8-55.
NG
Properly connect or replace the wiring har-
ness.
To Next Page
