9-166
U0155 or Err
EAS20649
U0155 or Err
EAS33129
TROUBLESHOOTING
Item
Multi-function meter: signals cannot be transmitted between the ECU and the multi-function meter.
Fail-safe system
• Able to start engine
• Able to drive vehicle
Procedure
“Err” is displayed on the clock display of the multi-function meter, but the MIL does not come on.
1. Connection of meter assembly coupler.
• Check the locking condition of the coupler.
• Disconnect the coupler and check the pins (bent or broken terminals and locking condition of the
pins).
2. Connection of ECU coupler.
• Check the locking condition of the coupler.
• Disconnect the coupler and check the pins (bent or broken terminals and locking condition of the
pins).
Is the coupler condition normal?
YES
Go to step 2.
NO
a. Connect the coupler securely or replace the wire harness.
b. Push the ON/start switch, and then check the condition of the DTC using the malfunction mode
of the YDT.
Is it in the “Recovered” condition?
YES
Go to step 6, and complete the service.
NO
Go to step 2.
Is the coupler condition normal?
YES
Go to step 3.
NO
a. Connect the coupler securely or replace the wire harness.
b. Push the ON/start switch, and then check the condition of the DTC using the malfunction mode
of the YDT.
Is it in the “Recovered” condition?
YES
Go to step 6, and complete the service.
NO
Go to step 3.
To Next Page
