9-23
CRUISE CONTROL SYSTEM (for XP560D)
EAS32879
[A] CHECKING THE CRUISE CONTROL SYSTEM INDICATOR LIGHT
Push the ON/start switch, and then push the cruise control power switch.
1. The cruise control system indicator light does not come on.
• Check the control power switch for continuity. Refer to “CHECKING THE SWITCHES” on page 8-
91. If there is no continuity, replace the handlebar switch (left).
• Check the fuse for continuity. Refer to “CHECKING THE FUSES” on page 8-93. If the cruise con-
trol system fuse is blown, replace the fuse.
• Check for continuity between the orange/white terminal of the handlebar switch coupler (left) and
orange/white terminal of the ECU (engine control unit) coupler. If there is no continuity, the wire
harness is defective. Replace the wire harness.
2. The cruise control system indicator light flashes. [B-1]
3. The cruise control system indicator light come on. [B-2]
EAS32880
[B-1] DIAGNOSIS USING THE DTC
1. Information for the DTCs from the cruise control system is contained in the following table. Refer to
this table for troubleshooting.
DTC table
EAS32881
[B-2] DIAGNOSIS USING THE MALFUNCTION HISTORY CODES
Check the malfunction history using the malfunction mode of the YDT.
• Malfunction history is displayed on the YDT. [B-1]
• Malfunction history is not displayed on the YDT. [B-3]
EAS32882
[B-3] MALFUNCTION HISTORY IS NOT DISPLAYED
Use the YDT to check whether automatic deactivation history for the cruise control system exists.
1. There is automatic deactivation history for the cruise control system.
• Explain the conditions for automatically deactivating the cruise control system to the customer.
• For information about the conditions for automatically deactivating the cruise control system.
If you do not have a YDT, the automatic deactivation history cannot be checked. Therefore, explain the
automatic deactivation function of the cruise control system to the customer and explain that this is not
a malfunction.
DTC No. Symptom Check point
P056C No normal signals from the switch are
received by the ECU.
• Wire harness (ECU coupler and front or rear
brake light switch coupler)
• Signaling system fuse and brake light fuses
• Connection of the brake light relay coupler
• Connection of the ignition system relay cou-
pler
• Front brake light switch
• Rear brake light switch
P0564 No normal signals from the switch are
received by the ECU.
• Wire harness (ECU coupler and handlebar
switch coupler (left))
• Ignition fuse and cruise control system fuse
• Connection of the ignition system relay cou-
pler
• Cruise control setting switch
To Next Page
