6-9
THERMOSTAT
EAS20065
THERMOSTAT
Removing the thermostat
Order Job/Parts to remove Q’ty Remarks
Bottom side cowling/Side panel/Bottom center
cowling
Refer to “GENERAL CHASSIS (1)” on
page 4-1.
Center cover/Fuel tank cover assembly/Side
cover/Rear side cowling assembly/Footboard
Refer to “GENERAL CHASSIS (2)” on
page 4-11.
Coolant
Drain.
Refer to “CHANGING THE COOLANT” on
page 3-31.
1 Thermostat cover 1
2 Thermostat 1
12
10 N・m (1.0 kgf・m, 7.4 lb・ft)
To Next Page
