4-61
REAR BRAKE
WARNING
EWA13540
• Use only the designated brake fluid. Other
brake fluids may cause the rubber seals to
deteriorate, causing leakage and poor
brake performance.
• Refill with the same type of brake fluid that
is already in the system. Mixing brake fluids
may result in a harmful chemical reaction,
leading to poor brake performance.
• When refilling, be careful that water does
not enter the brake master cylinder reser-
voir. Water will significantly lower the boil-
ing point of the brake fluid and could cause
vapor lock.
NOTICE
ECA13540
Brake fluid may damage painted surfaces
and plastic parts. Therefore, always clean up
any spilt brake fluid immediately.
5. Bleed:
• Brake system
Refer to “BLEEDING THE HYDRAULIC
BRAKE SYSTEM” on page 3-16.
6. Check:
• Brake fluid level
Below the minimum level mark  Add the
specified brake fluid to the proper level.
Refer to “CHECKING THE BRAKE FLUID
LEVEL” on page 3-14.
7. Check:
• Brake lever operation
Soft or spongy feeling  Bleed the brake sys-
tem.
Refer to “BLEEDING THE HYDRAULIC
BRAKE SYSTEM” on page 3-16.
EAS30193
REMOVING THE REAR BRAKE MASTER
CYLINDER
TIP
Before removing the rear brake master cylinder,
drain the brake fluid from the entire brake sys-
tem.
1. Remove:
• Brake hose union bolt
• Brake hose gasket
• Rear brake hose
TIP
To collect any remaining brake fluid, place a
container under the master cylinder and the end
of the brake hose.
EAS30194
CHECKING THE REAR BRAKE MASTER
CYLINDER
1. Check:
• Brake master cylinder
Damage/scratches/wear  Replace.
• Brake fluid delivery passage
(brake master cylinder body)
Obstruction  Blow out with compressed air.
2. Check:
• Brake master cylinder kit
Damage/scratches/wear  Replace.
3. Check:
• Brake master cylinder reservoir cap
• Brake master cylinder reservoir
• Brake master cylinder reservoir diaphragm
holder
Cracks/damage  Replace.
• Brake master cylinder reservoir diaphragm
Damage/wear  Replace.
4. Check:
• Brake hose
Cracks/damage/wear  Replace.
EAS30195
ASSEMBLING THE REAR BRAKE MASTER
CYLINDER
WARNING
EWA13520
• Before installation, all internal brake com-
ponents should be cleaned and lubricated
with clean or new brake fluid.
• Never use solvents on internal brake com-
ponents.
1. Install:
• Brake master cylinder kit
Specified brake fluid
DOT 4
Specified brake fluid
DOT 4
New
