5-2
LUBRICATION SYSTEM CHART AND DIAGRAMS
EAS32363
LUBRICATION DIAGRAMS
2
8
9
1
3
7
7
6
5
4
7
11
10
12
4
1. Exhaust camshaft
2. Intake camshaft
3. Oil delivery pipe
4. Oil pump assembly
5. Scavenge pump
6. Feed pump
7. Oil pipe
8. Oil cooler
9. Oil filter
10. Engine oil check bolt
11. Relief valve
12. Check valve
