8-93
ELECTRICAL COMPONENTS
EAS30551
CHECKING THE FUSES
The following procedure applies to all of the fus-
es.
ECA25770
To avoid a short circuit, always push the
OFF/LOCK switch when checking or replac-
ing a fuse.
1. Remove:
• Front cover
Refer to “GENERAL CHASSIS (1)” on
page 4-1.
2. Check:
•Fuse
a. Connect the digital circuit tester to the fuse
and check the continuity.
Set the digital circuit tester selector to “ ”.
b. If the digital circuit tester indicates “O.L”,
replace the fuse.
3. Replace:
• Fuse (blown fuse)
a. Push the OFF/LOCK switch.
b. Install a new fuse of the correct amperage
rating.
c. Set on the switches to verify if the electrical
circuit is operational.
d. If the fuse immediately blows again, check
the electrical circuit.
WARNING
EWA13310
Never use a fuse with an amperage rating
other than that specified. Improvising or us-
ing a fuse with the wrong amperage rating
may cause extensive damage to the electri-
cal system, cause the lighting and ignition
systems to malfunction and could possibly
cause a fire.
4. Install:
• Front cover
Refer to “GENERAL CHASSIS (1)” on
page 4-1.
EAS31006
REPLACING THE ECU (Engine Control Unit)
1. Push the ON/start switch (to OFF).
2. Replace the ECU (Engine Control Unit).
3. Clean the throttle bodies and reset the ISC
(Idle Speed Control) learning value.
Refer to “CHECKING AND CLEANING THE
THROTTLE BODIES” on page 7-10.
4. Check:
• Engine idling speed
Start the engine, warm it up, and then mea-
sure the engine idling speed.
Digital circuit tester (CD732)
90890-03243
Model 88 Multimeter with
tachometer
YU-A1927
Fuses
Amper-
age rating
Q’ty
Main 40 A 1
Headlight 7.5 A 1
Taillight 7.5 A 1
Electronic throttle valve 7.5 A 1
Signaling system 7.5 A 1
Ignition 7.5 A 1
Radiator fan motor 15 A 1
Fuel injection system 7.5 A 1
ABS motor 30 A 1
ABS control unit 7.5 A 1
ABS solenoid 15 A 1
Backup 15 A 1
Auxiliary DC jack 2 A 1
Seat lock (for XP560E) 7.5 A 1
Windshield motor
(for XP560D)
20 A 1
Brake light (for XP560D) 1 A 1
Cruise control
(for XP560D)
1 A 1
Spare 40 A 1
Spare 30 A 1
Spare 1 A 1
Spare 15 A 1
Spare (for XP560D) 20 A 1
Spare 7.5 A 1
Spare 2 A 1
Fuses
Amper-
age rating
Q’ty
