8-27
LIGHTING SYSTEM
EAS30499
TROUBLESHOOTING
Any of the following fail to light: headlight, auxiliary light, high beam indicator light, tail/brake light, li-
cense plate light, meter light or storage box light.
TIP
Before troubleshooting, remove the following part(s):
1. Leg shield assembly
2. Front cowling assembly
3. Mudguard
1. Check the each bulbs and bulb
sockets condition.
Refer to “CHECK THE BULBS
AND BULB SOCKETS” in “BASIC
INFORMATION” (separate vol-
ume).
NG Replace the bulb(s) and bulb socket.
OK
2. Check the fuses.
(Main, headlight, ignition, signaling
system and taillight)
Refer to “CHECKING THE FUS-
ES” on page 8-93.
NG Replace the fuse(s).
OK
3. Check the battery.
Refer to “CHECKING AND
CHARGING THE BATTERY” on
page 8-94.
NG
Clean the battery terminals.
Recharge or replace the battery.
OK
4. Check the ignition system relay.
Refer to “CHECKING THE RE-
LAYS” on page 8-94.
NG Replace the ignition system relay.
OK
5. Check the diode.
(Diode 3)
Refer to “CHECKING THE DI-
ODES” on page 8-101.
NG Replace the diode.
OK
6. Check the dimmer switch.
Refer to “CHECKING THE
SWITCHES” on page 8-91.
NG
The dimmer switch is faulty. Replace the
handlebar switch (left).
OK
7. Check the pass switch.
Refer to “CHECKING THE
SWITCHES” on page 8-91.
NG
The pass switch is faulty. Replace the
handlebar switch (left).
OK
