Yamaha TMAX TECH MAX 2020 User Manual

8-63
SEAT HEATER SYSTEM (for XP560D)
EAS32439
TROUBLESHOOTING
TIP
• Before troubleshooting, remove the following part(s):
1. Front cowling assembly
2. Footboards
3. Rear side cowling assembly
The seat heater does not become warm at all.
1. Check that the seat heater is not
turned off.
NG
Adjust the temperature levels of the seat
heater settings.
OK
2. Check the fuses.
(Main, signaling system, and back-
up)
Refer to “CHECKING THE FUS-
ES” on page 8-93.
NG Replace the fuse(s).
OK
3. Check that the engine is started. NG Start the engine.
OK
4. Check the battery.
Refer to “CHECKING AND
CHARGING THE BATTERY” on
page 8-94.
NG
• Clean the battery terminals.
• Recharge or replace the battery.
OK
5. Check the ignition system relay.
Refer to “CHECKING THE RE-
LAYS” on page 8-94.
NG Replace the ignition system relay.
OK
6. Check the seat heater relay
(power).
Refer to “CHECKING THE RE-
LAYS” on page 8-94.
NG Replace the seat heater relay (power).
OK
7. Check the seat heater relay
(control).
Refer to “CHECKING THE RE-
LAYS” on page 8-94.
NG Replace the seat heater relay (control).
OK
8. Check the seat heater.
Refer to “CHECKING THE SEAT
HEATER (for XP560D)” on page 8-
110.
NG Replace the seat heater.

Yamaha TMAX TECH MAX 2020 Specifications

General

Displacement	562 cc
Compression Ratio	10.9:1
Lubrication System	Wet sump
Fuel System	Fuel Injection
Ignition System	TCI
Starter System	Electric
Transmission System	V-Belt Automatic
Final Drive	Belt
Front Suspension System	Telescopic fork
Front Travel	120 mm
Rear Suspension System	Swingarm
Rear Travel	117 mm
Front Tyre	120/70-15
Seat Height	800 mm
Wheel Base	1, 575 mm
Minimum Ground Clearance	135 mm
Wet Weight	220 kg
Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-valve
Maximum Torque	55.7 Nm (5.7 kg-m) @ 5, 250 rpm
Front Brake	Dual 267 mm discs
Rear Brake	Single hydraulic disc
Rear Tyre	160/60-15
Fuel Tank Capacity	15 litres
Features	Heated Grips, Adjustable windscreen, Traction control
