Yamaha TMAX TECH MAX 2020 - Throttle Body

7-7
THROTTLE BODY
Removing the throttle body
Order Job/Parts to remove Q’ty Remarks
9 Throttle body joint 1
10 Fuel hose 1
11 Fuel rail 1
12 Injector 2
New
New
New
New
New
New
9
10
12
12
11
10 N・m (1.0 kgf・m, 7.4 lb・ft)
3.8 N・m (0.38 kgf・m, 2.8 lb・ft)
3.5 N・m (0.35 kgf・m, 2.6 lb・ft)
