Yamaha TMAX TECH MAX 2020 - Troubleshooting

8-53
WINDSHIELD DRIVE SYSTEM (for XP560D)
EAS30518
TROUBLESHOOTING
The windshield fails to move.
TIP
• Before troubleshooting, remove the following part(s):
1. Front cowling assembly
2. Rear side cowling assembly
3. Leg shield
1. Check that there are no rocks or
other foreign material in the wind-
shield drive unit side rails.
NG Remove the foreign material.
OK
2. Check that there is no foreign ma-
terial between the cable and the
pulley.
NG Remove the foreign material.
OK
3. Check the fuses.
(Main, ignition, backup, and wind-
shield motor)
Refer to “CHECKING THE FUS-
ES” on page 8-93.
NG Replace the fuse(s).
OK
4. Check the battery.
Refer to “CHECKING AND
CHARGING THE BATTERY” on
page 8-94.
NG
• Clean the battery terminals.
• Recharge or replace the battery.
OK
5. Check the ignition system relay.
Refer to “CHECKING THE
SWITCHES” on page 8-91.
NG Replace the ignition system relay.
OK
6. Check the menu switch.
Refer to “CHECKING THE
SWITCHES” on page 8-91.
NG
• The menu switch is faulty.
• Replace the handlebar switch (left).
OK
7. Check the select switch.
Refer to “CHECKING THE
SWITCHES” on page 8-91.
NG
• The select switch is faulty.
• Replace the handlebar switch (left).
OK
8. Check the windshield drive unit re-
lay (up).
Refer to “CHECKING THE RE-
LAYS” on page 8-94.
NG
Replace the windshield drive unit relay
(up).
