8-54
WINDSHIELD DRIVE SYSTEM (for XP560D)
OK
9. Check the windshield drive unit re-
lay (down).
Refer to “CHECKING THE RE-
LAYS” on page 8-94.
NG
Replace the windshield drive unit relay
(down).
OK
10.Check the windshield drive motor.
Refer to “CHECKING THE WIND-
SHIELD DRIVE UNIT (for
XP560D)” on page 8-109.
NG Replace the windshield drive unit.
OK
11.Check the entire windshield drive
system wiring.
Refer to “CIRCUIT DIAGRAM” on
page 8-51.
NG
Properly connect or replace the wire har-
ness.
OK
Replace the remote control unit and/
or meter assembly.
To Next Page
