V-BELT AUTOMATIC TRANSMISSION
Disassembling the primary sheave
*1 Apply YAMAHA GREASE “F”.
*2 When replacing the primary sliding sheave or collar, replace them as a set.
Order Job/Parts to remove Q’ty Remarks
1Cam 1
2 Slider 8
3 Primary sheave weight 8
4 Primary sliding sheave 1
5Collar 1
6 Oil seal 2
1
2
5
*
2
3
4
*
2
6
6
New
New
FWFWD
*
1
*
1
*
1
