2-36
CABLE ROUTING
1. Rear brake lock cable
2. Handlebar cover
3. Throttle cable (decelerator cable)
4. Throttle cable (accelerator cable)
5. Rear brake lock lever
6. Grip warmer (left)
7. Front brake hose (front brake master cylin-
der to hydraulic unit)
8. Front brake master cylinder
9. Throttle grip
10. Handlebar switch (right)
11. Handlebar switch (left)
12. Handlebar grip
13. Rear brake master cylinder
14. Rear brake hose (rear brake master cylin-
der to hydraulic unit)
15. Wire harness
16. Brake hose holder
A. Route the rear brake lock cable through
the hole in the handlebar cover.
B. Route through the cable guide in the order
of the throttle cable (decelerator cable) fol-
lowed by throttle cable (accelerator cable).
C. Install the grip warmer lead (left) into the
slot in the handlebar switch (left).
D. Turn the rear brake lock lever up to the
position shown in the illustration before
installing the rear brake lock cable.
E. 87– 93
F. Case mating surface of the handlebar
switch (left).
G. The end of the clamp should face the front
without being cut.
H. Route the grip warmer lead, handlebar
switch lead (right), and front brake light
switch lead on top of and behind the han-
dlebar.
I. Route the grip cancel switch lead between
the lower handlebar holder and the upper
bracket.
J. Route the grip warmer lead (left), handle-
bar switch lead (left), and rear brake light
switch lead on top of and behind the han-
dlebar.
K. The opening of the clamp should face the
front.
L. Insert the projection on the brake hose
holder into the hole on the lower bracket to
assemble it.
