2-52
CABLE ROUTING
1. Air filter element
2. Intake air pressure sensor
3. Fuel tank bracket
4. Throttle body assembly
5. Fuel tank
6. Air filter case
7. Fuel hose
8. Air filter case duct (right)
9. Canister purge hose (hose joint to canis-
ter)
10. Throttle body joint
11. Intake air pressure sensor hose
12. Air filter case duct (left)
13. Clamp
A. Insert the intake air pressure sensor hose
into the rounded area of the intake air pres-
sure sensor.
B. Assemble so the end face of the intake air
pressure sensor is aligned with the white
paint mark.
C. Mate the coolant temperature sensor lead
to the clamp on the air filter case duct
(right).
D. Insert the intake air pressure sensor hose
until it butts against the throttle body
assembly.
E. Do not allow the intake air pressure sensor
hose to be twisted.
F. Pass the intake air pressure sensor hose
under the brim of the air filter case duct
(left).
G. Mate the intake air pressure sensor hose
to the clamp on the air filter case duct (left).
H. 10ï‚°
I. Align the projection on the air filter case
duct (right) to the indent on the clamp.
J. Align the projection on the air filter case
duct (left) to the indent on the clamp.
K. Align the projection on the throttle body
joint to the indent on the clamp.
L. 23ï‚°
M. Insert the air filter case duct (left/right) until
it butts against the throttle body assembly.
N. 1-4 mm (0.04-0.16 in)
O. Install the hose clamp with its end the
screw head facing the right.
P. Insert the throttle body assembly until it
butts against the throttle body joint. Apply-
ing a coat of engine oil is a good idea.
To Next Page
