YASKAWA V1000 Technical Manual

0 0 0 0
0: 1800 r/min Series
1: 3600 r/min Series
2: 1750 r/min Series
3: 1450 r/min Series
4: 1150 r/min Series
F: Special Motor
Motor Voltage Class
and Capacity
0: Pico Motor
(SMRA Series)
1: Derated Torque for IPM
Motors
(SSR 1 Series)
Figure 5.44 PM Motor Code
n
E5-02: Motor Rated Power (PM OLV)
Sets the rated power of the motor.
No. Parameter Name Setting Range Default
E5-02 Motor Rated Power 0.10 to 18.50 kW
Depending on
E5-01
Note: This parameter is not reset when the drive is initialized using A1-03.
n
E5-03: Motor Rated Current (PM OLV)
Sets the motor rated current in amps.
No. Parameter Name Setting Range Default
E5-03 Motor Rated Current
10 to 200% of drive rated
current
Depending on
E5-01
Note: 1. Display is in the following units: BA0001 to BA0018, 2A0001 to 2A0040, and 4A0001 to 4A0023: 0.01 A units.
2A0056 to 2A0069, 4A0031 to 4A0038: 0.1 A units.
2. This parameter is not reset when the drive is initialized using A1-03.
n
E5-04: Number of Motor Poles (PM OLV)
Sets the number of motor poles.
No. Parameter Name Setting Range Default
E5-04 Number of Motor Poles 2 to 48
Depending on
E5-01
Note: This parameter is not reset when the drive is initialized using A1-03.
n
E5-05: Motor Stator Resistance (PM OLV)
Set the resistance for each motor phase (not line-to-line resistance). When measuring the resistance manually make sure
to enter the resistance of one phase into E5-05.
No. Parameter Name Setting Range Default
E5-05 Motor Stator Resistance 0.000 to 65.000 Ω
Depending on
E5-01
Note: This parameter is not reset when the drive is initialized using A1-03.
n
E5-06: Motor d Axis Inductance (PM OLV)
Sets
the d axis inductance in units of
0.01 mH. Contact the motor manufacturer for d-axis inductance. If an LCR meter is
available, enter half the value of the measurement taken.
No. Parameter Name Setting Range Default
E5-06 Motor d Axis Inductance 0.00 to 300.00 mH
Depending on
E5-01
Note: This parameter is not reset when the drive is initialized using A1-03.
n
E5-07: Motor q Axis Inductance (PM OLV)
Sets
the q axis inductance in units of
0.01 mH. Contact the motor manufacturer for d-axis inductance. If an LCR meter is
available, enter half the value of the measurement taken.
No. Parameter Name Setting Range Default
E5-07 Motor q Axis Inductance 0.00 to 600.00 mH
Depending on
E5-01
Note: This parameter is not reset when the drive is initialized using A1-03.
5.5 E: Motor Parameters
YASKAWA ELECTRIC SIEP C710606 16C YASKAWA AC Drive – V1000 Technical Manual
171
5
Parameter Details

YASKAWA V1000 Specifications

General

Input Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Frequency	0-400 Hz
Control Method	V/f control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Options	Modbus RTU
Ambient Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20°C to +65°C (-4°F to 149°F)
Humidity	95% (non-condensing)
Cooling Method	Forced Air Cooling
Enclosure	IP20
