Table B.7 Three-Phase, 200 V Class Drives Default Settings by Drive Capacity and ND/HD settings
No. Description Unit Default Settings
Model 2A0001 2A0002 2A0004 2A0006 2A0008
o2-04 Drive Model Selection 96 (60H) 97 (61H) 98 (62H) 99 (63H) 100 (64H)
C6-01 Normal/Heavy Duty
HD ND HD ND HD ND HD ND HD ND
0 1 0 1 0 1 0 1 0 1
E2-11
(E4-11,
T1-02)
Motor rated power kW 0.1 0.2 0.2 0.4 0.4 0.75 0.75 1.1 1.1 1.5
b3-06 Speed Search current 1 1.0 1.0 1.0 1.0 1.0 1.0 0.5 0.5 0.5 0.5
b3-08
Current Control Gain during Speed
Search (Speed Estimation Type)
0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5
b8-04 Energy saving coefficient 481.7 356.9 356.9 288.2 288.2 223.7 223.7 196.6 196.6 169.4
C6-02 Carrier frequency 4 7 4 7 4 7 4 7 3 7
E2-01
(E4-01,
T1-04)
Motor rated current A 0.6 1.1 1.1 1.9 1.9 3.3 3.3 4.9 4.9 6.2
E2-02
(E4-02)
Motor rated slip Hz 2.5 2.6 2.6 2.9 2.9 2.5 2.5 2.6 2.6 2.6
E2-03
(E4-03)
Motor no-load current A 0.4 0.8 0.8 1.2 1.2 1.8 1.8 2.3 2.3 2.8
E2-05
(E4-05)
Motor line-to-line resistance Ω 35.98 20.56 20.56 9.84 9.842 5.156 5.156 3.577 3.577 1.997
E2-06
(E4-06)
Motor leakage inductance % 21.6 20.1 20.1 18.2 18.2 13.8 13.8 18.5 18.5 18.5
E2-10
(E4-10)
Motor Iron Loss W 6 11 11 14 14 26 26 38 38 53
E5-01 Motor Code hex FFFF FFFF FFFF FFFF 0002 0002 0003 0003 FFFF FFFF
L2-02
Momentary power loss ride-
through time
s 0.1 0.1 0.1 0.1 0.1 0.1 0.2 0.2 0.3 0.3
L2-03
Momentary power loss Baseblock
time
s 0.2 0.2 0.2 0.2 0.2 0.3 0.3 0.4 0.4 0.4
L2-04
Momentary power loss voltage
recovery time
s 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3
L2-05 Uv detection voltage V dc 190 190 190 190 190 190 190 190 190 190
L3-24 Motor acceleration time s 0.178 0.178 0.178 0.178 0.178 0.142 0.142 0.142 0.142 0.166
L8-02 Overheat alarm level °C 110 110 110 110 115 115 100 100 100 100
L8-09 Ground fault selection 0 0 0 0 0 0 0 0 0 0
L8-35 Installation method selection 0 0 0 0 0 0 0 0 0 0
L8-38
Carrier frequency reduction
selection
1 1 1 1 1 1 1 1 1 1
n1-03 Hunting Prevention Time Constant ms 10 10 10 10 10 10 10 10 10 10
n2-01
Speed Feedback Detection Control
(AFR) Gain
1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00
B.6 Defaults by Drive Model and Duty Rating (ND/HD)
