YASKAWA V1000

No. Description Unit Default Settings
− Model − 2A0010 2A0012 2A0018 2A0020 2A0030
o2-04 Drive Model Selection − 101 (65H) 102 (66H) 103 (67H) 104 (68H) 105 (6AH)
C6-01 Normal/Heavy Duty −
HD ND HD ND HD ND HD ND HD ND
0 1 0 1 0 1 0 1 0 1
E2-11
(E4-11,
T1-02)
Motor rated power kW 1.5 2.2 2.2 3.0 3.0 3.7 3.7 5.5 5.5 7.5
b3-06 Speed Search current 1 − 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5
b3-08
Current Control Gain during Speed
Search (Speed Estimation Type)
– 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5
b8-04 Energy saving coefficient − 169.4 156.8 156.8 136.4 136.4 122.9 122.9 94.8 94.75 72.69
C6-02 Carrier frequency − 3 7 3 7 3 7 3 7 3 7
E2-01
(E4-01,
T1-04)
Motor rated current A 6.2 8.5 8.5 11.4 11.4 14 14 19.6 19.6 26.6
E2-02
(E4-02)
Motor rated slip Hz 2.6 2.9 2.9 2.7 2.7 2.73 2.73 1.5 1.5 1.3
E2-03
(E4-03)
Motor no-load current A 2.8 3.0 3.0 3.7 3.7 4.5 4.5 5.1 5.1 8.0
E2-05
(E4-05)
Motor line-to-line resistance Ω 1.997 1.601 1.601 1.034 1.034 0.771 0.771 0.399 0.399 0.288
E2-06
(E4-06)
Motor leakage inductance % 18.5 18.4 18.4 19 19 19.6 19.6 18.2 18.2 15.5
E2-10
(E4-10)
Motor Iron Loss W 53 77 77 91 91 112 112 172 172 262
E5-01 Motor Code hex 0005 0005 0006 0006 FFFF FFFF 0008 0008 FFFF FFFF
L2-02
Momentary power loss ride-
through time
s 0.3 0.3 0.5 0.5 1 1 1 1 1.0 1.0
L2-03
Momentary power loss Baseblock
time
s 0.4 0.5 0.5 0.5 0.5 0.6 0.6 0.7 0.7 0.8
L2-04
Momentary power loss voltage
recovery time
s 0.3 0.3 0.3 0.3 0.3 0.6 0.3 0.6 0.3 0.3
L2-05 Uv detection voltage V dc 190 190 190 190 190 190 190 190 190 190
L3-24 Motor acceleration time s 0.166 0.145 0.145 0.145 0.145 0.154 0.154 0.168 0.168 0.175
L8-02 Overheat alarm level °C 100 100 100 100 110 110 110 110 115 115
L8-09 Ground fault selection − 0 0 0 0 0 0 0 0 1 1
L8-35 Installation method selection − 0 0 0 0 0 0 0 0 2 2
L8-38
Carrier frequency reduction
selection
− 1 1 1 1 1 1 1 1 2 2
n1-03 Hunting Prevention Time Constant ms 10 10 10 10 10 10 10 10 10 10
n2-01
Speed Feedback Detection Control
(AFR) Gain
– 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.50 1.50
B.6 Defaults by Drive Model and Duty Rating (ND/HD)
