Table B.14 400 V, 1750 rpm Type Yaskawa SSR1 Series Motor
Par. Description Unit Default Settings
E5-01
Motor Code − 1232 1233 1235 1236 1238 123A 123B 123D 123E 123F
Voltage Class − 400 Vac 400 Vac 400 Vac 400 Vac 400 Vac 400 Vac 400 Vac 400 Vac 400 Vac 400 Vac
Rated Power − 0.4 kW 0.75 kW 1.5 kW 2.2 kW 3.7 kW 5.5 kW 7.5 kW 11 kW 15 kW 18 kW
Rated Speed r/min 1750 1750 1750 1750 1750 1750 1750 1750 1750 1750
E5-02 Motor Rated Power kW 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5
E5-03 Motor Rated Current A 0.89 1.56 2.81 4.27 7.08 10.31 13.65 20.7 27.5 33.4
E5-04 Motor Pole Number – 6 6 6 6 6 6 6 6 6 6
E5-05
Motor Winding
Resistance
Ω 25.370 9.136 6.010 3.297 1.798 0.982 0.786 0.349 0.272 0.207
E5-06 d-Axis Inductance mH 169.00 92.08 67.71 34.40 32.93 22.7 16.49 13.17 10.30 8.72
E5-07 q-Axis Inductance mH 197.5 119.56 81.71 54.00 37.7 26.8 23.46 15.60 12.77 11.22
E5-09
Induction Voltage
Constant 1
mVs/rad 392.6 440.6 478.3 466.3 478.8 478.1 520.0 481.5 498.8 509.5
E5-24
Induction Voltage
Constant 2
mV/(r/
min)
0 0 0 0 0 0 0 0 0 0
E1-04
Maximum Output
Frequency
Hz 87.5 87.5 87.5 87.5 87.5 87.5 87.5 87.5 87.5 87.5
E1-05
Maximum Output
Voltage
V 380 380 380 380 380 380 380 380 380 380
E1-06 Base Frequency Hz 87.5 87.5 87.5 87.5 87.5 87.5 87.5 87.5 87.5 87.5
E1-09
Minimum Output
Frequency
Hz 4.4 4.4 4.4 4.4 4.4 4.4 4.4 4.4 4.4 4.4
L3-24
<1>
Motor Acceleration
Time for Inertia
Calculations
s 0.092 0.076 0.051 0.066 0.075 0.083 0.077 0.084 0.102 0.101
n8-49
d-Axis Current for
High-Efficiency
Control
% –8.6 –11.5 –10.3 –19.8 –8.5 –11 –18.6 –12.5 –15.5 –17.9
<1> Default setting value is dependent on parameter o2-04, Drive Model Selection.
B.7 Parameters that Change with the Motor Code Selection
394
YASKAWA ELECTRIC SIEP C710606 16C YASKAWA AC Drive – V1000 Technical Manual

YASKAWA V1000 Specifications

General

Input Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Frequency	0-400 Hz
Control Method	V/f control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Options	Modbus RTU
Ambient Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20°C to +65°C (-4°F to 149°F)
Humidity	95% (non-condensing)
Cooling Method	Forced Air Cooling
Enclosure	IP20
