YASKAWA V1000 Technical Manual

n
Drive Software Version PRG: 1017 and Earlier
Table B.15 200 V, 1450 rpm Type Yaskawa SSR1 Series Motor
Par. Description Unit Default Settings
E5-01
Motor Code − 1302 1303 1305 1306 1308 130A 130B 130D 130E 130F
Voltage Class − 200 Vac 200 Vac 200 Vac 200 Vac 200 Vac 200 Vac 200 Vac 200 Vac 200 Vac 200 Vac
Rated Power − 0.4 kW 0.75 kW 1.5 kW 2.2 kW 3.7 kW 5.5kW 7.5 kW 11 kW 15 kW 18 kW
Rated Speed r/min 1450 1450 1450 1450 1450 1450 1450 1450 1450 1450
E5-02 Motor Rated Power kW 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11.0 15 18.0
E5-03 Motor Rated Current A 1.78 3.12 5.88 8.00 14.10 20.00 26.60 38.0 53.3 63.0
E5-04 Motor Pole Number – 6 6 6 6 6 6 6 6 6 6
E5-05
Motor Winding
Resistance
Ω 4.405 2.425 1.647 0.665 0.452 0.341 0.184 0.099 0.075 0.057
E5-06 d-Axis Inductance mH 26.62 19.14 14.53 12.27 7.10 5.90 6.91 4.07 3.29 2.53
E5-07 q-Axis Inductance mH 41.70 29.98 19.98 14.77 10.14 8.42 8.37 5.25 4.57 3.01
E5-09
Induction Voltage
Constant 1
mVs/rad 262.6 276.3 291.0 299.1 294.3 306.6 325.1 316.6 332.2 313.4
E5-24
Induction Voltage
Constant 2
mV/(r/
min)
0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
E1-04
Maximum Output
Frequency
Hz 72.5 72.5 72.5 72.5 72.5 72.5 72.5 72.5 72.5 72.5
E1-05
Maximum Output
Voltage
V 190.0 190.0 190.0 190.0 190.0 190.0 190.0 190.0 190.0 190.0
E1-06 Base Frequency Hz 72.5 72.5 72.5 72.5 72.5 72.5 72.5 72.5 72.5 72.5
E1-09
Minimum Output
Frequency
Hz 3.6 3.6 3.6 3.6 3.6 3.6 3.6 3.6 3.6 3.6
L3-24
<1>
Motor Acceleration
Time for Inertia
Calculations
s 0.098 0.071 0.066 0.087 0.085 0.072 0.084 0.096 0.085 0.082
n8-49
d-Axis Current for
High-Efficiency
Control
% –10.8 –13.1 –12.1 –8.4 –16.0 –17.8 –12.8 –16.3 –19.1 –11.6
<1> Default setting value is dependent on parameter o2-04, Drive Model Selection.
B.7 Parameters that Change with the Motor Code Selection
YASKAWA ELECTRIC SIEP C710606 16C YASKAWA AC Drive – V1000 Technical Manual
395
B
Parameter List

YASKAWA V1000 Specifications

General

Input Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Frequency	0-400 Hz
Control Method	V/f control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Options	Modbus RTU
Ambient Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20°C to +65°C (-4°F to 149°F)
Humidity	95% (non-condensing)
Cooling Method	Forced Air Cooling
Enclosure	IP20
