YASKAWA V1000

n
Drive Software Version PRG: 1018 and Later
Table B.16 200 V, 1450 rpm Type Yaskawa SSR1 Series Motor
Par. Description Unit Default Settings
E5-01
Motor Code − 1302 1303 1305 1306 1308 130A 130B 130D 130E 130F
Voltage Class − 200 Vac 200 Vac 200 Vac 200 Vac 200 Vac 200 Vac 200 Vac 200 Vac 200 Vac 200 Vac
Rated Power − 0.4 kW 0.75 kW 1.5 kW 2.2 kW 3.7 kW 5.5 kW 7.5 kW 11 kW 15 kW 18 kW
Rated Speed r/min 1450 1450 1450 1450 1450 1450 1450 1450 1450 1450
E5-02 Motor Rated Power kW 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5
E5-03 Motor Rated Current A 1.88 3.13 5.63 8.33 14.17 20.63 27.71 39.6 55.5 65.6
E5-04 Motor Pole Number – 6 6 6 6 6 6 6 6 6 6
E5-05
Motor Winding
Resistance
Ω 3.190 1.940 1.206 0.665 0.341 0.252 0.184 0.099 0.075 0.057
E5-06 d-Axis Inductance mH 32.15 26.12 14.72 12.27 8.27 6.49 6.91 4.07 3.29 2.53
E5-07 q-Axis Inductance mH 41.74 34.3 20.15 14.77 9.81 7.74 7.66 4.65 3.84 3.01
E5-09
Induction Voltage
Constant 1
mVs/rad 264.3 269.6 284.3 287.1 284.5 298.0 335.0 303.9 311.2 300.9
E5-24
Induction Voltage
Constant 2
mV/(r/
min)
0 0 0 0 0 0 0 0 0 0
E1-04
Maximum Output
Frequency
Hz 72.5 72.5 72.5 72.5 72.5 72.5 72.5 72.5 72.5 72.5
E1-05
Maximum Output
Voltage
V 190 190 190 190 190 190 190 190 190 190
E1-06 Base Frequency Hz 72.5 72.5 72.5 72.5 72.5 72.5 72.5 72.5 72.5 72.5
E1-09
Minimum Output
Frequency
Hz 3.6 3.6 3.6 3.6 3.6 3.6 3.6 3.6 3.6 3.6
L3-24
<1>
Motor Acceleration
Time for Inertia
Calculations
s 0.098 0.071 0.066 0.087 0.085 0.072 0.084 0.096 0.085 0.08
n8-49
d-Axis Current for
High-Efficiency
Control
% –6.6 –10.9 –13.5 –9 –9.5 –10.1 –6 –9.3 –10.7 –13.2
<1> Default setting value is dependent on parameter o2-04, Drive Model Selection.
B.7 Parameters that Change with the Motor Code Selection
396
YASKAWA ELECTRIC SIEP C710606 16C YASKAWA AC Drive – V1000 Technical Manual
