YASKAWA V1000

n
Drive Software Version PRG: 1017 and Earlier
Table B.17 400 V, 1450 rpm Type Yaskawa SSR1 Series Motor
Par. Description Unit Default Settings
E5-01
Motor Code − 1332 1333 1335 1336 1338 133A 133B 133D 133E 133F
Voltage Class − 400 Vac 400 Vac 400 Vac 400 Vac 400 Vac 400 Vac 400 Vac 400 Vac 400 Vac 400 Vac
Rated Power − 0.4 kW 0.75 kW 1.5 kW 2.2 kW 3.7 kW 5.5 kW 7.5 kW 11 kW 15 kW 18 kW
Rated Speed r/min 1450 1450 1450 1450 1450 1450 1450 1450 1450 1450
E5-02 Motor Rated Power kW 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11.0 15 18.0
E5-03 Motor Rated Current A 0.89 1.50 2.70 4.10 6.70 9.80 13.30 18.7 26.3 31.5
E5-04 Motor Pole Number – 6 6 6 6 6 6 6 6 6 6
E5-05
Motor Winding
Resistance
Ω 17.620 7.421 4.825 2.656 1.353 0.999 0.713 0.396 0.295 0.223
E5-06 d-Axis Inductance mH 106.50 85.11 58.87 46.42 31.73 26.20 27.06 15.22 12.65 9.87
E5-07 q-Axis Inductance mH 166.80 113.19 80.59 60.32 40.45 30.94 33.45 19.63 15.87 12.40
E5-09
Induction Voltage
Constant 1
mVs/rad 525.2 566.9 592.2 579.4 586.4 612.1 640.4 643.5 650.6 635.8
E5-24
Induction Voltage
Constant 2
mV/(r/
min)
0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
E1-04
Maximum Output
Frequency
Hz 72.5 72.5 72.5 72.5 72.5 72.5 72.5 72.5 72.5 72.5
E1-05
Maximum Output
Voltage
V 380.0 380.0 380.0 380.0 380.0 380.0 380.0 380.0 380.0 380.0
E1-06 Base Frequency Hz 72.5 72.5 72.5 72.5 72.5 72.5 72.5 72.5 72.5 72.5
E1-09
Minimum Output
Frequency
Hz 3.6 3.6 3.6 3.6 3.6 3.6 3.6 3.6 3.6 3.6
L3-24
<1>
Motor Acceleration
Time for Inertia
Calculations
s 0.098 0.071 0.066 0.087 0.085 0.072 0.084 0.096 0.085 0.082
n8-49
d-Axis Current for
High-Efficiency
Control
% –10.8 –8.5 –12.5 –12.2 –12.7 –9.4 –14.4 –15.0 –14.1 –14.3
<1> Default setting value is dependent on parameter o2-04, Drive Model Selection.
B.7 Parameters that Change with the Motor Code Selection
YASKAWA ELECTRIC SIEP C710606 16C YASKAWA AC Drive – V1000 Technical Manual
397
B
Parameter List
