Drive Software Version PRG: 1018 and Later
Table B.18 400 V, 1450 rpm Type Yaskawa SSR1 Series Motor
Par. Description Unit Default Settings
E5-01
Motor Code − 1332 1333 1335 1336 1338 133A 133B 133D 133E 133F
Voltage Class − 400 Vac 400 Vac 400 Vac 400 Vac 400 Vac 400 Vac 400 Vac 400 Vac 400 Vac 400 Vac
Rated Power − 0.4 kW 0.75 kW 1.5 kW 2.2 kW 3.7 kW 5.5 kW 7.5 kW 11 kW 15 kW 18 kW
Rated Speed r/min 1450 1450 1450 1450 1450 1450 1450 1450 1450 1450
E5-02 Motor Rated Power kW 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5
E5-03 Motor Rated Current A 0.94 1.56 2.81 4.27 6.98 10.21 13.85 19.5 27.4 32.9
E5-04 Motor Pole Number – 6 6 6 6 6 6 6 6 6 6
E5-05
Motor Winding
Resistance
Ω 12.76 7.421 4.825 2.656 1.353 0.999 0.713 0.393 0.295 0.223
E5-06 d-Axis Inductance mH 128.6 85.11 58.87 46.42 31.73 26.2 27.06 15.51 12.65 9.87
E5-07 q-Axis Inductance mH 166.96 113.19 80.59 60.32 40.45 30.94 33.45 19.63 15.87 12.4
E5-09
Induction Voltage
Constant 1
mVs/rad 528.6 544.2 568.5 572.8 562.9 587.6 670.1 612.7 624.6 610.4
E5-24
Induction Voltage
Constant 2
mV/(r/
min)
0 0 0 0 0 0 0 0 0 0
E1-04
Maximum Output
Frequency
Hz 72.5 72.5 72.5 72.5 72.5 72.5 72.5 72.5 72.5 72.5
E1-05
Maximum Output
Voltage
V 380 380 380 380 380 380 380 380 380 380
E1-06 Base Frequency Hz 72.5 72.5 72.5 72.5 72.5 72.5 72.5 72.5 72.5 72.5
E1-09
Minimum Output
Frequency
Hz 3.6 3.6 3.6 3.6 3.6 3.6 3.6 3.6 3.6 3.6
L3-24
<1>
Motor Acceleration
Time for Inertia
Calculations
s 0.098 0.071 0.066 0.087 0.085 0.072 0.084 0.096 0.085 0.08
n8-49
d-Axis Current for
High-Efficiency
Control
% –6.6 –9.2 –13.5 –12.1 –13.7 –10.1 –12.2 –15.5 –15.1 –16
<1> Default setting value is dependent on parameter o2-04, Drive Model Selection.
