YASKAWA V1000 Technical Manual

n
Drive Software Version PRG: 1017 and Earlier
Table B.19 200 V, 1150 rpm Type Yaskawa SSR1 Series Motor
Par. Description Unit Default Settings
E5-01
Motor Code − 1402 1403 1405 1406 1408 140A 140B 140D 140E 140F
Voltage Class − 200 Vac 200 Vac 200 Vac 200 Vac 200 Vac 200 Vac 200 Vac 200 Vac 200 Vac 200 Vac
Rated Power − 0.4 kW 0.75 kW 1.5 kW 2.2 kW 3.7 kW 5.5kW 7.5 kW 11 kW 15 kW 18 kW
Rated Speed r/min 1150 1150 1150 1150 1150 1150 1150 1150 1150 1150
E5-02 Motor Rated Power kW 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11.0 15.0 18.0
E5-03 Motor Rated Current A 1.74 3.17 5.9 8.84 13.7 18.6 25.8 38.6 53.4 63.8
E5-04 Motor Pole Number – 6 6 6 6 6 6 6 6 6 6
E5-05
Motor Winding
Resistance
Ω 6.763 3.660 1.480 0.696 0.412 0.414 0.262 0.149 0.084 0.083
E5-06 d-Axis Inductance mH 42.88 28.59 17.64 10.40 7.94 10.60 7.53 4.49 3.83 2.78
E5-07 q-Axis Inductance mH 67.17 44.78 24.23 14.85 11.86 14.92 10.97 6.82 4.65 4.39
E5-09
Induction Voltage
Constant 1
mVs/rad 333.3 337.7 365.5 356.2 359.2 428.2 410.0 389.8 387.6 392.6
E5-24
Induction Voltage
Constant 2
mV/(r/
min)
0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
E1-04
Maximum Output
Frequency
Hz 57.5 57.5 57.5 57.5 57.5 57.5 57.5 57.5 57.5 57.5
E1-05
Maximum Output
Voltage
V 190.0 190.0 190.0 190.0 190.0 190.0 190.0 190.0 190.0 190.0
E1-06 Base Frequency Hz 57.5 57.5 57.5 57.5 57.5 57.5 57.5 57.5 57.5 57.5
E1-09
Minimum Output
Frequency
Hz 2.9 2.9 2.9 2.9 2.9 2.9 2.9 2.9 2.9 2.9
L3-24
<1>
Motor Acceleration
Time for Inertia
Calculations
s 0.062 0.044 0.080 0.090 0.067 0.072 0.088 0.073 0.063 0.093
n8-49
d-Axis Current for
High-Efficiency
Control
% –13.5 –16.3 –11.8 –12.3 –18.2 –18.7 –21.8 –24.0 –13.4 –25.4
<1> Default setting value is dependent on parameter o2-04, Drive Model Selection.
B.7 Parameters that Change with the Motor Code Selection
YASKAWA ELECTRIC SIEP C710606 16C YASKAWA AC Drive – V1000 Technical Manual
399
B
Parameter List

YASKAWA V1000 Specifications

General

Input Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Frequency	0-400 Hz
Control Method	V/f control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Options	Modbus RTU
Ambient Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20°C to +65°C (-4°F to 149°F)
Humidity	95% (non-condensing)
Cooling Method	Forced Air Cooling
Enclosure	IP20
