YASKAWA V1000 Technical Manual

n
Drive Software Version PRG: 1018 and Later
Table B.20 200 V, 1150 rpm Type Yaskawa SSR1 Series Motor
Par. Description Unit Default Settings
E5-01
Motor Code − 1402 1403 1405 1406 1408 140A 140B 140D 140E 140F
Voltage Class − 200 Vac 200 Vac 200 Vac 200 Vac 200 Vac 200 Vac 200 Vac 200 Vac 200 Vac 200 Vac
Rated Power − 0.4 kW 0.75 kW 1.5 kW 2.2 kW 3.7 kW 5.5 kW 7.5 kW 11 kW 15 kW 18 kW
Rated Speed r/min 1150 1150 1150 1150 1150 1150 1150 1150 1150 1150
E5-02 Motor Rated Power kW 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5
E5-03 Motor Rated Current A 1.88 3.02 6.00 8.85 14.27 20.21 26.67 39.9 55.6 63.5
E5-04 Motor Pole Number – 6 6 6 6 6 6 6 6 6 6
E5-05
Motor Winding
Resistance
Ω 4.832 2.704 1.114 0.511 0.412 0.303 0.165 0.113 0.084 0.066
E5-06 d-Axis Inductance mH 48.68 32.31 19.22 12.15 7.94 11.13 6.59 4.96 3.83 3.33
E5-07 q-Axis Inductance mH 63.21 40.24 24.38 15.35 11.86 14.06 8.55 6.12 4.65 4.5
E5-09
Induction Voltage
Constant 1
mVs/rad 320.4 327.1 364.4 344.4 357.5 430.8 391.5 384.4 372.1 421.3
E5-24
Induction Voltage
Constant 2
mV/(r/
min)
0 0 0 0 0 0 0 0 0 0
E1-04
Maximum Output
Frequency
Hz 57.5 57.5 57.5 57.5 57.5 57.5 57.5 57.5 57.5 57.5
E1-05
Maximum Output
Voltage
V 190 190 190 190 190 190 190 190 190 190
E1-06 Base Frequency Hz 57.5 57.5 57.5 57.5 57.5 57.5 57.5 57.5 57.5 57.5
E1-09
Minimum Output
Frequency
Hz 2.9 2.9 2.9 2.9 2.9 2.9 2.9 2.9 2.9 2.9
L3-24
<1>
Motor Acceleration
Time for Inertia
Calculations
s 0.062 0.044 0.08 0.09 0.067 0.072 0.088 0.073 0.062 0.091
n8-49
d-Axis Current for
High-Efficiency
Control
% –8.8 –9.9 –9.3 –10 –17.7 –12.3 –15.3 –13.9 –14.4 –17.9
<1> Default setting value is dependent on parameter o2-04, Drive Model Selection.
B.7 Parameters that Change with the Motor Code Selection
400
YASKAWA ELECTRIC SIEP C710606 16C YASKAWA AC Drive – V1000 Technical Manual

YASKAWA V1000 Specifications

General

Input Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Frequency	0-400 Hz
Control Method	V/f control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Options	Modbus RTU
Ambient Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20°C to +65°C (-4°F to 149°F)
Humidity	95% (non-condensing)
Cooling Method	Forced Air Cooling
Enclosure	IP20
