YASKAWA V1000 Technical Manual

n
Drive Software Version PRG: 1017 and Earlier
Table B.21 400 V, 1150 rpm Type Yaskawa SSR1 Series Motor
Par. Description Unit Default Settings
E5-01
Motor Code − 1432 1433 1435 1436 1438 143A 143B 143D 143E 143F
Voltage Class − 400 Vac 400 Vac 400 Vac 400 Vac 400 Vac 400 Vac 400 Vac 400 Vac 400 Vac 400 Vac
Rated Power − 0.4 kW 0.75 kW 1.5 kW 2.2 kW 3.7 kW 5.5kW 7.5 kW 11 kW 15 kW 18 kW
Rated Speed r/min 1150 1150 1150 1150 1150 1150 1150 1150 1150 1150
E5-02 Motor Rated Power kW 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11.0 15 18.0
E5-03 Motor Rated Current A 0.87 1.59 2.95 4.42 6.80 9.70 12.60 19.1 26.7 31.9
E5-04 Motor Pole Number – 6 6 6 6 6 6 6 6 6 6
E5-05
Motor Winding
Resistance
Ω 27.050 14.640 5.291 2.783 1.480 1.220 0.655 0.443 0.334 0.332
E5-06 d-Axis Inductance mH 171.50 114.40 70.56 41.61 38.39 45.97 25.46 18.84 15.27 11.10
E5-07 q-Axis Inductance mH 268.70 179.10 96.90 59.41 47.65 56.26 33.63 24.68 18.56 17.56
E5-09
Induction Voltage
Constant 1
mVs/rad 666.9 675.5 731.0 712.4 792.7 859.9 820.2 805.4 796.4 785.1
E5-24
Induction Voltage
Constant 2
mV/(r/
min)
0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
E1-04
Maximum Output
Frequency
Hz 57.5 57.5 57.5 57.5 57.5 57.5 57.5 57.5 57.5 57.5
E1-05
Maximum Output
Voltage
V 380.0 380.0 380.0 380.0 380.0 380.0 380.0 380.0 380.0 380.0
E1-06 Base Frequency Hz 57.5 57.5 57.5 57.5 57.5 57.5 57.5 57.5 57.5 57.5
E1-09
Minimum Output
Frequency
Hz 2.9 2.9 2.9 2.9 2.9 2.9 2.9 2.9 2.9 2.9
L3-24
<1>
Motor Acceleration
Time for Inertia
Calculations
s 0.062 0.044 0.080 0.090 0.067 0.072 0.088 0.073 0.062 0.093
n8-49
d-Axis Current for
High-Efficiency
Control
% –13.5 –16.2 –11.8 –12.3 –8.8 –11.5 –14.8 –15.6 –12.5 –25.4
<1> Default setting value is dependent on parameter o2-04, Drive Model Selection.
B.7 Parameters that Change with the Motor Code Selection
YASKAWA ELECTRIC SIEP C710606 16C YASKAWA AC Drive – V1000 Technical Manual
401
B
Parameter List

YASKAWA V1000 Specifications

General

Input Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Frequency	0-400 Hz
Control Method	V/f control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Options	Modbus RTU
Ambient Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20°C to +65°C (-4°F to 149°F)
Humidity	95% (non-condensing)
Cooling Method	Forced Air Cooling
Enclosure	IP20
